Connection kit size 20, stroke 150 mm, port G1/8 DADG-AK-G8-20-150 - Festo 8159797

Connection kit DADG-AK-G8-20-150 feeds a size 20 drive with 150 mm stroke with compressed air via G1/8. The kit weighs 58.6 g and is designed for compressed air to ISO 8573-1:2010 [7:4:4].

Why this part

• Port G1/8, max. tightening torque 3 Nm
• Mounting with max. 3 Nm tightening torque, tolerance ± 10 %
• Operating pressure 1 to 8 bar
• Adapter made of epoxy resin, seals made of FPM
• Corrosion resistance class CRC 1, rated for low corrosion stress
• Ambient temperature -10 to 60 °C

Where it is used

For drives in handling and assembly, at -10 to 60 °C ambient temperature and in paint shops with PWIS requirements.
