Push-in T-connector stainless steel for tubing OD 5/16" CRQST-5/16T-U - Festo 565352

Festo ✓ Original product Brand new

Push-in T-connector CRQST-5/16T-U for fast tubing connections, tubing OD 5/16" on all ports. Operating pressure ranges from -0.95 to 14 bar across the full temperature range. Housing made of high-alloy stainless steel, tubing seal made of FPM. Corrosion resistance class 4.

Net
€75.31
excl. VAT
Item FES-565352
Manufacturer no. CRQST-5/16T-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The push-in T-connector CRQST-5/16T-U plugs tubing together as a T-branch, tubing OD 5/16" on all ports. To connect, the 5/16" tubing is simply pushed in (push-pull principle), to release, the release ring is pressed.

Benefits

  • Vacuum and pressure operating pressure -0.95 to 14 bar across the full temperature range
  • Temperature range ambient temperature -20 to 150 °C
  • Corrosion protection corrosion resistance class CRC 4 - very high corrosion stress
  • Materials housing, release ring and clamping segment made of high-alloy stainless steel, tubing seal made of FPM
  • Nominal width 6.502 mm
  • Installation tubing insertion depth 16 mm

Application

Typical use of CRQST-5/16T-U: for tubing distribution where one line supplies two consumers. Medium for CRQST-5/16T-U: compressed air to ISO 8573-1:2010 [7:-:-]. Any mounting position is allowed. Suitable tubing: PFAN.

Technical data

TypeCRQST-5/16T-U
Festo part number565352
SizeStandard
Nominal width6.502 mm
Tubing insertion depth16 mm
Mounting positionany
ShapeT-shape
Designpush-pull principle
Operating pressure across the full temperature range-0.95 to 14 bar
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Corrosion resistance class CRC4 - very high corrosion stress
PWIS (LABS) conformityVDMA24364 zone III
Food compatibilitysee extended material information
Ambient temperature-20 to 150 °C
Suitable tubingPFAN
Pneumatic connection 1For tubing OD 5/16"
Pneumatic connection 2For tubing OD 5/16"
Release ring coloursilver
Material noteRoHS compliant
Housing materialHigh-alloy stainless steel
Release ring materialHigh-alloy stainless steel
Tube seal materialFPM
Tube clamping segment materialHigh-alloy stainless steel
ManufacturerFesto
Hersteller-NrCRQST-5/16T-U
EAN4052568367756
Zolltarifnummer73072910
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialStainless steel
BauformT-Form
Size BGStandard
Seal materialFPM
MediumCompressed air
SeriesCRQST
Betriebsdruck max [bar]14
Temperaturbereich-20-150 °C
Temperature (max.)150
