Push-in L-fitting stainless steel male thread 3/8 NPTF to tubing OD 1/2" CRQSL-3/8-1/2-U - Festo 565332
Push-in L-fitting CRQSL-3/8-1/2-U for fast tubing connections, male thread 3/8 NPTF to tubing OD 1/2". Operating pressure -0.95 to 14 bar, covering vacuum and positive pressure. Housing made of high-alloy stainless steel, tubing seal made of FPM. Corrosion resistance class 4.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The push-in L-fitting CRQSL-3/8-1/2-U screws in via its male thread 3/8 NPTF and leads plastic tubing with OD 1/2" away at a right angle. Following the push-pull principle, inserting the 1/2" tubing is enough to connect, release is via the release ring.
Benefits
- Vacuum and pressure operating pressure -0.95 to 14 bar across the full temperature range
- Corrosion protection corrosion resistance class CRC 4 - very high corrosion stress
- Temperature range ambient temperature -20 to 150 °C
- Materials housing, release ring and clamping segment made of high-alloy stainless steel, tubing seal made of FPM
- Nominal width 10.49 mm
- Installation external hexagon A/F 13/16, tubing insertion depth 19.5 mm
Application
Application of CRQSL-3/8-1/2-U: for ports with little space in front of the device where the tubing should leave sideways. Medium for CRQSL-3/8-1/2-U: compressed air to ISO 8573-1:2010 [7:-:-]. Any mounting position is allowed. Suitable tubing: PFAN.
Technical data
| Type | CRQSL-3/8-1/2-U |
|---|---|
| Festo part number | 565332 |
| Size | Standard |
| Nominal width | 10.49 mm |
| Tubing insertion depth | 19.5 mm |
| Mounting position | any |
| Shape | L-shape |
| Design | push-pull principle |
| Operating pressure across the full temperature range | -0.95 to 14 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class CRC | 4 - very high corrosion stress |
| PWIS (LABS) conformity | VDMA24364 zone III |
| Food compatibility | see extended material information |
| Ambient temperature | -20 to 150 °C |
| Suitable tubing | PFAN |
| Mounting type | External hexagon A/F 13/16 |
| Pneumatic connection 1 | Male thread 3/8 NPTF |
| Pneumatic connection 2 | For tubing OD 1/2" |
| Release ring colour | silver |
| Material note | RoHS compliant |
| Housing material | High-alloy stainless steel |
| Release ring material | High-alloy stainless steel |
| Tube seal material | FPM |
| Tube clamping segment material | High-alloy stainless steel |
| Manufacturer | Festo |
| Hersteller-Nr | CRQSL-3/8-1/2-U |
| EAN | 4052568367558 |
| Zolltarifnummer | 73072910 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Stainless steel |
| Bauform | L-Form |
| Size BG | Standard |
| Seal material | FPM |
| Medium | Compressed air |
| Thread type | External thread |
| Series | CRQSL |
| Betriebsdruck max [bar] | 14 |
| Temperaturbereich | -20-150 °C |
| Temperature (max.) | 150 |
