EtherCAT interface for CPX-AP-I, EtherCAT protocol, 24 V DC, IP65 CPX-AP-I-EC-M12 - Festo 8086609
The etherCAT interface CPX-AP-I-EC-M12 connects the CPX-AP-I system to the higher-level controller. Key data: EtherCAT protocol, nominal operating voltage 24 V DC and power failure bridging 10 ms. In addition: reverse polarity protection and transmission rate 100 Mbit/s.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The etherCAT interface CPX-AP-I-EC-M12 connects the CPX-AP-I system to the higher-level controller. For system design, the relevant data are EtherCAT protocol and nominal operating voltage 24 V DC.
Advantages
- Fieldbus connection via EtherCAT
- Nominal operating voltage 24 V DC
- Power failure bridging 10 ms
- Integrated reverse polarity protection
- Transmission rate 100 Mbit/s
- IP65/IP67 protection for mounting directly on the machine
Application
CPX-AP-I-EC-M12 is used to build and extend automation solutions based on the CPX-AP-I system.
Technical data
| Type | CPX-AP-I-EC-M12 |
|---|---|
| Festo part number | 8086609 |
| Dimensions (W x L x H) | 45 mm x 170 mm x 35 mm |
| Type of mounting | On DIN rail via accessories, With through-hole |
| Max. number of modules | 80 |
| Product weight | 186 g |
| Ambient temperature | -20 to 60 °C |
| Storage temperature | -40 to 70 °C |
| Relative air humidity | 5 - 95%, Non-condensing |
| Degree of protection | IP65, IP67 |
| Note on degree of protection | Unused connections sealed |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| Max. cable length | 50 m system communication |
| Note on max. cable length | Power supply according to nominal voltage |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| UKCA marking (see declaration of conformity) | To UK instructions for EMC |
| KC mark | KC-EMV |
| Approval | RCM, c UL us - Listed (Oil) |
| Certificate issuing authority | UL E239998 |
| Note on materials | RoHS compliant |
| Material housing | Makrolon, Nickel-plated die-cast zinc |
| Material o-ring | Fluoro rubber |
| Diagnostics via LED | Diagnostics per module, EtherCAT RUN, Power supply, electronics/sensors, Load power supply, System diagnostics, Maintenance required |
| Diagnostics via bus | Electronics/sensors overvoltage, Load overvoltage, Electronics/sensors undervoltage, Load undervoltage |
| Diagnostics per internal communication | Module error, Output short circuit/overload, Short circuit/overload in sensor supply, Load supply undervoltage |
| Fieldbus interface | Ethernet |
| Field bus, protocol | EtherCAT |
| Fieldbus interface, function | Bus connection incoming/outgoing |
| Field bus, connection type | 2x socket |
| Field bus, connection system | M12x1, D-coded to EN 61076-2-101 |
| Field bus, connection pattern | 4 |
| Field bus interface, electrical isolation | Yes |
| Field bus interface, transmission rate | 100 Mbit/s |
| Max. address volume, inputs | 2048 byte |
| Max. address volume, outputs | 2048 byte |
| Configuration support | ESI file |
| Communication interface, function | System communication XF20 OUT / XF21 OUT |
| Communication interface, connection type | 2x socket |
| Communication interface, connection technology | M8x1, D-coded according to EN 61076-2-114 |
| Communication interface, number of pins/cores | 4 |
| Communication interface, protocol | AP |
| Communication interface, screened | Yes |
| Power supply, function | Incoming electronics/sensors and load |
| Power supply, connection type | Plug |
| Power supply, connection system | M8x1, A-coded to EN 61076-2-104 |
| Power supply, number of pins/wires | 4 |
| Power transmission, function | Outgoing electronics/sensors and load |
| Power transmission, connection type | Socket |
| Power transmission, connection technology | M8x1, A-coded to EN 61076-2-104 |
| Power transmission, number of pins/wires | 4 |
| Note regarding operating voltage | SELV/PELV fixed power supplies required, Note the voltage drop |
| Nominal operating voltage DC of load | 24 V |
| Permissible voltage fluctuation of load | ± 25 % |
| Nominal DC operating voltage, electronics/sensors | 24 V |
| Permissible voltage fluctuations for electronics/sensors | ± 25 % |
| Max. power supply | 2 x 4 A (external fuse required) |
| Intrinsic current consumption at nominal operating voltage for electronics/sensors | Typically 90 mA |
| Intrinsic current consumption at nominal operating voltage load | Typically 5 mA |
| Power failure bridging | 10 ms |
| Reverse polarity protection | Yes |
| Weight | 0.21 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CPX-AP-I-EC-M12 |
| EAN | 4052568456603 |
| Zolltarifnummer | 85176200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 24 V DC |
| Protection rating | IP65 |
| Temperaturbereich | -20-60 °C |
| Temperature (max.) | 60 |
