Control system as control cabinet 230 V AC CMCB-D1-CC-S0 - Festo 8118456
The Festo control system CMCB-D1-CC-S0 comes as a control cabinet, category B, Performance Level b. Key data: dimensions W x L x H 220 mm x 350 mm x 440 mm, degree of protection IP54, rated operating voltage 230 V AC, 50 to 60 Hz.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo control system CMCB-D1-CC-S0 comes as a control cabinet, category B, Performance Level b. Dimensions W x L x H 220 mm x 350 mm x 440 mm, product weight 15 kg.
Why choose the CMCB-D1-CC-S0
- Dimensions W x L x H 220 mm x 350 mm x 440 mm
- Degree of protection IP54
- Rated operating voltage 230 V AC, 50 to 60 Hz
- Power supply up to 6 A, secondary circuit 5 A
- Push-in electrical connection
- Ambient temperature 5 to 40 °C
Applications
The CMCB-D1-CC-S0 (control cabinet, IP54) is used to supply and control Festo handling systems in industrial indoor areas. It runs on 230 V AC in TT, TN and IT networks, for residential areas Festo points to possible radio interference suppression measures.
Technical data
| Order type | CMCB-D1-CC-S0 |
|---|---|
| Festo part number | 8118456 |
| Instructions on use | the product is suitable for industrial purposes only. Measures to eliminate radio interference may be required in residential areas |
| Design | control cabinet |
| Performance Level (PL) | category B, Performance Level b |
| Dimensions (W x L x H) | 220 mm x 350 mm x 440 mm |
| Fuse protection (short circuit) | internal electronic fuse |
| Maximum current consumption | 1100 mA |
| Current consumption of the secondary circuit | 5 A |
| Maximum power supply | 6 A |
| Nominal operating voltage AC | 230 V |
| Mains types | TT, PN, IT |
| Mains frequency | 50 to 60 Hz |
| Pollution degree | 2 |
| CE mark (see declaration of conformity) | to EU EMC Directive, to EU Low Voltage Directive |
| Corrosion resistance class CRC | 0 - no corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 to 60 °C |
| Relative air humidity | max. 50% at 40 °C |
| Protection against direct and indirect contact | PELV, earthing of all exposed conductive parts |
| Degree of protection | IP54 |
| Environmental conditions | interior |
| Ambient temperature | 5 to 40 °C |
| Nominal altitude of use | 1000 m NN |
| Product weight | 15000 g |
| Electrical connection | Push-in |
| Note on materials | RoHS compliant |
| Customs tariff number | 85371091 |
| Weight | 17 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CMCB-D1-CC-S0 |
| EAN | 4052568556013 |
| Zolltarifnummer | 85371091 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 230 V AC |
| Protection rating | IP54 |
| Temperature (max.) | 40 |
