Sensorinterface CASB-MT-D3-R7 - Festo 8071781

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Sensor interface 24 V DC IP65 with TTL and HTL output, M12 connections CASB-MT-D3-R7 - Festo 8071781

Festo ✓ Original product Brand new

The sensor interface CASB-MT-D3-R7 provides the sensor signal at two outputs as TTL signal up to 7200 Hz and HTL signal up to 450 Hz. Supply 24 V DC, degree of protection IP65 when mounted, all connections M12x1.

Net
€438.48
excl. VAT
Item FES-8071781
Manufacturer no. CASB-MT-D3-R7
Save Compare
Question about this item
Datasheet (PDF)
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo sensor interface CASB-MT-D3-R7 has connections for sensor (2x socket), valve and two outputs, all M12x1 A-coded to EN 61076-2-101. It runs on 20.4 to 30 V operating voltage, draws a maximum of 6 W and shows its status via LED.

Benefits

  • TTL and HTL output, TTL up to 7200 Hz, HTL up to 450 Hz
  • Operating voltage 20.4 to 30 V, nominal voltage 24 V, reverse polarity protection
  • Degree of protection IP65 when mounted, PELV protection against contact
  • M12x1 connections to EN 61076-2-101
  • Shock and vibration resistance to EN 60068-2-27 and EN 60068-2-6, severity level 2
  • Ambient temperature -5 to 50 °C, duty cycle 100%

Applications

The sensor interface is intended for industrial use only. Measures to eliminate radio interference may be required in residential areas. It is mounted via a through-hole for an M4 screw.

Technical data

Instructions on useThe product is suitable for industrial purposes only. Measures to eliminate radio interference may be required in residential areas.
Diagnostic functionDisplay via LED
Mounting positionAny
Reverse polarity protectionYes
Output frequencyTTL-Signal: max. 7200 Hz, HTL signal: max. 450 Hz
Operational voltage range DC20.4 to 30 V
Duty cycle100%
Max. electrical power consumption6 W
Nominal operating voltage DC24 V
Residual ripple5%
Current consumption with no-load outputs50 mA
Current rating per output50 mA
ApprovalRCM
KC markKC-EMV
CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
Vibration resistanceTransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Shock resistanceShock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Protection against direct and indirect contactPELV
Degree of protectionIP65
Note on degree of protectionIn mounted state
Ambient temperature-5 to 50 °C
Product weight350 g
analog inputHTL signal: high: min. 18 V, low: max. 2 V, TTL signal: high: min. 2.4 V, low: max. 0.4 V
Electrical connection output, functionTTL
Electrical connection output, connection typePlug
Electrical connection output, connector systemM12x1, A-coded to EN 61076-2-101
Electrical connection output, number of connections/cores8
Electrical connection for output 2, functionHTL
Electrical connection for output 2, connection typePlug
Electrical connection for output 2, connection technologyM12x1, A-coded to EN 61076-2-101
Electrical connection output 2, number of pins/wires5
Electrical connection for valve, connection typePlug
Electrical connection for valve, connection technologyM12x1, A-coded to EN 61076-2-101
Electrical connection for valve, number of pins/wires8
Electrical connection for sensor, connection type2x socket
Electrical connection for sensor, connection technologyM12x1, A-coded to EN 61076-2-101
Electrical connection for sensor, number of pins/wires8
Type of mountingVia through-hole for M4 screw
Note on materialsRoHS compliant
Material sealsFluoro rubber, NBR
Material housingAnodised wr
Weight0.36 kg
ManufacturerFesto
Hersteller-NrCASB-MT-D3-R7
EAN4052568445874
Zolltarifnummer85371098
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Operating voltage24 V DC
Protection ratingIP65
Temperature (max.)50
