Manifold block single-acting G1/4 380 l/min CAPS-M1-VDE1-S-A-AL-G14 - Festo 8154576

Festo ✓ Original product Brand new

The Festo CAPS-M1-VDE1-S-A-AL-G14 manifold block is mounted in accordance with VDI/VDE 3845 and feeds compressed air single-acting at 380 l/min standard nominal flow to the actuator. Port G1/4. Safety position: pneumatic output 2 exhausted. Mounting in accordance with VDI/VDE 3845.

Net
€88.10
excl. VAT
Item FES-8154576
Manufacturer no. CAPS-M1-VDE1-S-A-AL-G14
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo CAPS-M1-VDE1-S-A-AL-G14 manifold block is mounted in accordance with VDI/VDE 3845 and feeds compressed air single-acting at 380 l/min standard nominal flow to the actuator.

Why choose it

  • Standard nominal flow rate 380 l/min
  • Safety position: pneumatic output 2 exhausted
  • Mounting in accordance with VDI/VDE 3845
  • LABS (PWIS) conformity VDMA24364 zone III
  • Housing made of aluminium, powder-coated

Applications

The pneumatic port is G1/4, the housing is made of aluminium, powder-coated.

Technical data

TypeCAPS-M1-VDE1-S-A-AL-G14
Festo part number8154576
Dimensions (W x L x H)65 mm x 104 mm x 28 mm
Mode of operationSingle-acting
Design characteristicsSafety position: pneumatic output 2 exhausted
Standard nominal flow rate (standardised to DIN 1343)380 l/min
LABS (PWIS) conformityVDMA24364 zone III
Product weight465 g
Type of mountingin accordance with VDI/VDE 3845
Pneumatic connectionG1/4
Note on materialsRoHS compliant
Material screwsHigh-alloy stainless steel
Material housingAluminium, powder-coated
Weight0.5 kg
ManufacturerFesto
Hersteller-NrCAPS-M1-VDE1-S-A-AL-G14
EAN4052568577216
Zolltarifnummer76169990
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/4
