C002 series inline lockout valve, 1-1/2 PTF, NC, 3/2, lever on both sides - Norgren C0024D
The state is read from the position of the actuator. The C002 series inline lockout valve Norgren C0024D seals with nitrile rubber (nbr), polyurethane (pu) and is suitable for compressed air.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Shut-off valves separate the plant from the air supply and vent the circuit for maintenance. The C002 series inline lockout valve Norgren C0024D seals with nitrile rubber (nbr), polyurethane (pu) and works at an operating pressure of 0 to 20 bar.
Benefits
- Three way manually operated lockout valve, lockable in the closed position with a padlock
- Helps comply with OSHA regulation 29 CFR Part 1910 for lockout procedures
- Port size 1-1/2 PTF
- Operating pressure 0 to 20 bar
- Flow 11120 l/min
- Temperature range -30 to 80 °C
Applications
Typical installations are supply lines that must be secured before maintenance.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren C0024D |
| Series | CR04 |
| Valve function | 3/2 |
| Function | NC |
| Actuation | Lever / Lever |
| Valve technology | Spool |
| Spool and sleeve | Aluminium |
| Port size | 1-1/2 PTF |
| Operating pressure | 0 to 20 bar |
| Flow | 11120 l/min |
| Exhaust flow | 7590 l/min |
| Medium | Compressed air |
| Temperature range | -30 to 80 °C |
| Body material | Aluminium |
| Seal material | Nitrile rubber (NBR), Polyurethane (PU) |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | C0024D |
| Zolltarifnummer | 84814090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
