4/3 directional spool valve size 6, 12 V DC, 4WE6M6X/EG12N9K4/V - Bosch Rexroth R978026993
As a 4/3 directional spool valve, Bosch Rexroth 4WE6M6X/EG12N9K4/V switches the oil flow to cylinders and hydraulic motors, rated for 350 bar and up to 70 l/min. Size 6, subplate mounting with mounting pattern ISO 4401-03-02-0-05, spool symbol M.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
4WE6M6X/EG12N9K4/V is a 4/3 directional spool valve from Bosch Rexroth in size 6, rated for up to 350 bar and 70 l/min. Manufacturer class: high performance range.
Why this valve
- Withstands operating pressures up to 350 bar
- Up to 70 l/min flow in size 6
- Standardised pattern ISO 4401-03-02-0-05 for replacement without modifying the subplate
- 4 ports, 3 switching positions, spool symbol M
- 12 V DC solenoid with connector, 3-pole (2 + PE) according to EN 175301-803
- Seals made of FKM
Applications
Typical tasks are extending, retracting and holding hydraulic cylinders and switching hydraulic motors in machine building and industrial hydraulics. When replacing an existing valve, the complete type code 4WE6M6X/EG12N9K4/V on the rating plate is decisive, material number R978026993 identifies the version unambiguously.
Technical data
| Type | 4WE6M6X/EG12N9K4/V |
|---|---|
| Material number | R978026993 |
| Manufacturer | Bosch Rexroth |
| Size | 6 |
| Operating pressure max. | 350 bar |
| Max. flow | 70 l/min |
| Number of ports | 4 |
| Number of switching positions | 3 |
| Spool symbol | Symbol M |
| Type of actuation | with solenoid actuation |
| Connection diagram | ISO 4401-03-02-0-05 |
| Supply voltage | 12 V DC |
| Electrical connection | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Seals | FKM |
| Hydraulic fluid | HL |
| Weight | 1.94 kg |
| Hersteller-Nr | R978026993 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Seal material | FKM |
| Function | 4/3 |
| Flow rate [l/min] | 70 |
| Actuation type | Electrical |
| Norm | ISO 4401 |
| Operating voltage | 12 V DC |
| Betriebsdruck max [bar] | 350 |
Downloads
Datasheet
- Datasheet (PDF)
- Directional spool valves, direct operated (RE 23178) EN
- Directional spool valves, pilot-operated (RE 24751) EN
- Proportional directional valve, pilot-operated (RE 29115) EN
- Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) DE
- Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung DE
- Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) DE
