Pressure Relief Valve DBW30B2-5X/200S6EG24N9K4R12/12=CSA - Bosch Rexroth R978020511

The setting range runs from 4 to 200 bar, covering power units that work well below the 350 bar limit of the valve. Up to 650 l/min discharges across the subplate interface to ISO 6264-10-17, since the valve belongs to size 32. Adjustment happens on the internal hexagon under the protective cap and solenoid actuation switches the circuit in two positions.

Benefits

• Setting range of 4 to 200 bar, maximum operating pressure 350 bar
• Flow up to 650 l/min across the subplate interface to ISO 6264-10-17
• Pilot-operated poppet design keeps leakage limited in the closed position
• Internal hexagon with protective cap, the chosen value stays covered
• Solenoid actuation at 24 VDC in two switching positions, 3-pole connector (2 + PE) to EN 175301-803
• Mass 6.3 kg in size 32, NBR seals for HL hydraulic fluid

Technical data

Application

Its usual place is the pump outlet of a power unit whose loads run at 200 bar or less. Solenoid actuation unloads the circuit from the control system without touching the pressure setting. Size 32 matches pumps delivering up to 650 l/min.

Manufacturer

Bosch Rexroth lists this pressure relief valve DBW30B2-5X/200S6EG24N9K4R12/12=CSA under material number R978020511. Data sheets RE 25802 and RE 25802-B carry the characteristic curves, the installation dimensions and the interface data. Compare the interface of your subplate against ISO 6264-10-17 before ordering.
