4/3 directional spool valve size 6 4WE 6 E6X/EG96N9K4/62, spool E, 96 V DC - Bosch Rexroth R978017789
Bosch Rexroth 4/3 directional spool valve 4WE 6 E6X/EG96N9K4/62 for operating pressures up to 350 bar and flow rates up to 80 l/min. Control is by solenoids (96 V DC) with a 3-pole connector (2 + PE) to EN 175301-803. NBR seals for hydraulic fluid HL, spool symbol E.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Rated for up to 350 bar operating pressure and 80 l/min flow, the directional valve 4WE 6 E6X/EG96N9K4/62 sets the flow direction in the hydraulic circuit. Control is by solenoids (96 V DC) with a 3-pole connector (2 + PE) to EN 175301-803. The spool has three switching positions according to symbol E.
Benefits
- Up to 350 bar operating pressure for hydraulic circuits in the high performance range
- 80 l/min maximum flow at size 6
- Connection diagram ISO 4401-03-02-0-05 for standardised subplates
- Connector to EN 175301-803 for 96 V DC
- NBR seals for hydraulic fluid HL
- UKCA: UKCA marking to Low Voltage Directive SI2016/1101
Applications
The valve 4WE 6 E6X/EG96N9K4/62 controls hydraulic cylinders and hydraulic motors in industrial hydraulics and machine building. For replacement, the valve is clearly identified by material number R978017789.
Technical data
| Type | 4WE 6 E6X/EG96N9K4/62 |
|---|---|
| Material number | R978017789 |
| Size | 6 |
| Operating pressure max. | 350 bar |
| Max. flow | 80 l/min |
| Connection diagram | ISO 4401-03-02-0-05 |
| Number of ports | 4 |
| Number of switching positions | 3 |
| Spool symbol | E |
| Type of actuation | solenoid actuation |
| Supply voltage | 96 V DC |
| Electrical connection | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Seals | NBR |
| Hydraulic fluid | HL |
| Conformity | UKCA, Low Voltage Directive SI2016/1101 |
| Weight | 1.95 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R978017789 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Ausführung | 4WE 6 E6X/EG96N9K4/62 |
| Seal material | NBR |
| Function | 4/3 |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 350 |
