Pressure Relief Valve DBW30B2-5X/100YUS6EG24N9K4R12/12 - Bosch Rexroth R978010809

The DBW30B2-5X/100YUS6EG24N9K4R12/12 limits system pressure across a range of 2 to 100 bar and discharges up to 650 l/min. The setting is fixed through an internal hexagon with protective cap, and a mounted solenoid valve unloads the circuit on command.

Benefits

• Flow up to 650 l/min in size 32
• Pressure setting range 2 to 100 bar through an internal hexagon with protective cap
• Electric unloading at 24 VDC, spool symbol B
• Pilot-operated poppet valve, closing tight after relief
• Operating pressure of 350 bar maximum, NBR seals
• 6.3 kg mass, subplate mounting to ISO 6264-10-17

Technical data

Application

The valve protects circuits that move large oil volumes at low pressure, such as prefill and return stages of large presses. Its unloading function switches the circuit to zero pressure during pauses without stopping the pump.

Manufacturer

Bosch Rexroth lists this pressure relief valve DBW30B2-5X/100YUS6EG24N9K4R12/12 under material number R978010809. Data sheets RE 25802 and RE 25802-B carry the characteristic curves, the installation dimensions and the subplate data.
