Vorsteuerventil 3DREP 6 C-2X/25EG24N6JK10/V-899*ET - Bosch Rexroth R961005293

An adjustment range up to 25 bar makes this valve a command stage for pilot-operated sections. The 3DREP 6 C-2X/25EG24N6JK10/V-899*ET is directly actuated in size 6, carries up to 15 l/min and takes up to 100 bar operating pressure.

Benefits

• Pressure adjustment range up to 25 bar at 100 bar maximum operating pressure at the port.
• Manual override with mushroom button, the stage can be switched by hand without energising it.
• Directly actuated spool valve with 15 l/min flow on the ISO 4401-03-02-0-05 pattern.
• Three switching positions across four ports with the paths P to A, P to B as well as A to T and B to T.
• 3-pole (2 + PE) bayonet plug to VG 95234, 24 VDC, FKM seals, 2.82 kg weight.

Technical data

Applications

The valve serves as a command stage for pilot-operated pressure and directional valves and for adjusting pumps. The bayonet plug to VG 95234 is laid out for applications with raised vibration loads. Control is handled by external electronics that set the current for the proportional solenoid.

Manufacturer

Bosch Rexroth, material number R961005293. Characteristic curves and adjustment range data are taken from the manufacturer documentation for this valve family.
