Proportional Directional Valve 4WREE10E25-3X/M/24A1 - Bosch Rexroth R901582131

Name: Proportional Directional Valve 4WREE10E25-3X/M/24A1 - Bosch Rexroth R901582131
Brand: Bosch Rexroth
SKU: BRR-R901582131
Price: 2422.36 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Replacing an older proportional valve comes down to mounting pattern, symbol and signal type. The 4WREE10E25-3X/M/24A1 sits on ISO 4401-05-04-0-05, carries spool symbol E and takes ±10 V as its command value. 25 l/min nominal flow, 7.3 kg.

Net

€2,422.36

excl. VAT

Item BRR-R901582131

Manufacturer no. R901582131

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

In a retrofit the existing wiring usually decides which valve can be considered. The 4WREE10E25-3X/M/24A1 accepts the widespread ±10 V command voltage, works at 25 l/min nominal flow, and brings its electronics along.

Benefits

±10 V command voltage, matched to analog outputs already present in the controller.
25 l/min nominal flow at 350 bar, flow up to 180 l/min.
ISO 4401-05-04-0-05 pattern, spool symbol E, four ports, three switching positions.
Digital electronics inside the valve, 24 VDC at the 7-pole connector (6 + PE) to EN 175201-804.
NBR seals, 7.3 kg, HL fluid, UKCA to SI2016/1091.

Application

The typical case is swapping a valve of the same size inside an existing manifold. Because electronics live in the valve, the control cabinet stays untouched. Before the swap, spool symbol and nominal flow have to be compared with the outgoing unit.

Manufacturer

Bosch Rexroth, material number R901582131. Product family 4WREE 10, version 4WREE10E25-3X/M/24A1.

Technical data

Conformity description	UKCA - Electromagnetic compatibility (EMC) SI2016/1091
Connection diagram	ISO 4401-05-04-0-05
Max. flow	180 l/min
Product family	4WREE 10
Type of connection	Subplate mounting
Nominal flow	25 l/min
Conformity	UKCA
Supply voltage	24 VDC
Connectivity	Analog, command value ±10 V
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector, 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol E
Operating pressure, max.	350 bar
Size	10
Seals	NBR
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	7.3 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901582131
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany

Downloads

Datasheet

Datasheet (PDF) PDF
Directional spool valves, direct operated (RE 23178) PDF, 1.2 MB, 28 p. EN
Directional spool valves, pilot-operated (RE 24751) PDF, 1.3 MB, 40 p. EN
Proportional directional valve, pilot-operated (RE 29115) PDF, 1.5 MB, 28 p. EN
Proportional directional valves, direct operated, with electrical position feedback and integrated (RE 29106) PDF, 2.2 MB, 36 p. EN
Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) PDF, 1.5 MB, 28 p. DE
Proportional-Wegeventile, direktgesteuert, mit elektrischer Wegrückführung und integrierter (RD 29106) PDF, 2.2 MB, 36 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung PDF, 1.2 MB, 28 p. DE
Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) PDF, 1.6 MB, 40 p. DE
