Where a load-holding axis needs 75 l/min, this version covers it with the closed centre of symbol E1 and FKM seals. Size 10, up to 180 l/min maximum flow, 350 bar operating pressure and a 4...20 mA current command.
Proportional Directional Valve 4WREE10E1-75-3X/V/24F1 - Bosch Rexroth R901577883
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,680.90
Item
BRR-R901577883
Manufacturer no.
R901577883
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901577883
Country of originGermany
ConditionNew
Artikel
BRR-R901577883
Frequently Bought Together
-
This Item:
€2,680.90
-
Directional Spool Valve 4WMM6D5X/F/B20 - Bosch Rexroth R900370807
€619.15
-
Proportional Directional Valve 4WRLE25R5-350SJ-4X/MPT/24L1-247 - Bosch Rexroth R901575537
€6,970.45
Total price
A larger oil demand and a held load are not mutually exclusive. The 4WREE10E1-75 releases 75 l/min nominal flow, opens to 180 l/min maximum flow at peaks and still blocks all four ports in mid position. The version is sealed with FKM, and the on-board electronics take the command value as 4...20 mA.
Benefits
- 75 l/min nominal flow, up to 180 l/min maximum flow in size 10
- Closed centre to spool symbol E1, the load stays held without an extra valve
- FKM seals matched to HL class hydraulic fluid
- 4...20 mA command value, on-board digital electronics, 24 VDC supply
- Operating pressure up to 350 bar, subplate mounting to ISO 4401-05-04-0-05
- 7.3 kg unit weight, 7-pole connector (6 + PE) to EN 175201-804, UKCA conformity for EMC SI2016/1091
Technical data
| Product family | 4WREE 10 |
| Size | 10 |
| Connection diagram | ISO 4401-05-04-0-05 |
| Type of connection | Subplate mounting |
| Nominal flow | 75 l/min |
| Max. flow | 180 l/min |
| Operating pressure, max. | 350 bar |
| Spool symbol | Symbol E1 |
| Number of switching positions | 3 |
| Number of ports | 4 |
| Type of actuation | Electrical with on-board electronics |
| Connectivity | Analog, command value 4...20 mA |
| Supply voltage | 24 VDC |
| Electrical connection description | Connector, 7-pole (6 + PE) according to EN 175201-804 |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Seals | FKM |
| Hydraulic fluid | HL |
| Conformity | UKCA |
| Conformity description | UKCA - Electromagnetic compatibility (EMC) SI2016/1091 |
| Weight | 7.3 kg |
Application
This combination is wanted on lifting axes, press infeeds and test cylinders that travel briskly and then stand under load. The current command stays stable over longer cable runs. The standard ISO 4401-05-04-0-05 pattern allows a swap against existing valves of the same size.
Manufacturer
The Bosch Rexroth material number is R901577883.
| Hersteller-Nr | R901577883 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 7.300000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
