Not every hydraulic fluid gets along with NBR. The Z3DREA6VP1-2X/50G24K31A1V is therefore built with FKM seals and regulates within the 50 bar rating, driven by a 0...10 V command value at its on-board electronics.
Proportional Pressure Valve Z Z3DREA6VP1-2X/50G24K31A1V - Bosch Rexroth R901551850
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,168.82
Item
BRR-R901551850
Manufacturer no.
R901551850
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901551850
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901551850
Frequently Bought Together
-
This Item:
€2,168.82
-
Directional Spool Valve 4WE6D6X/EG48K4 - Bosch Rexroth R900970128
€172.68
-
Directional Spool Valve 4WE6D6X/EG24N9K4/B28V - Bosch Rexroth R900957244
€188.23
Total price
The sealing material decides whether a valve may stay in a circuit at all. The Z3DREA6VP1-2X/50G24K31A1V carries FKM seals and works within the 50 bar rating, its command value arriving as 0...10 V at the on-board electronics.
Benefits
- FKM seals, suited to circuits where the sealing material is prescribed.
- 50 bar pressure rating for axes with low clamping pressure, at 350 bar permissible operating pressure.
- 0...10 V command value at on-board electronics, no extra amplifier card required.
- Size 6, up to 60 l/min on the ISO 4401-03-02-0-05 interface in sandwich plate form.
- 3.5 kg weight, 4 ports, 3 switching positions, 24 VDC supply through a 7-pole plug.
Technical data
| Conformity description | UKCA - Electromagnetic compatibility (EMC) SI2016/1091 |
| Connection diagram | ISO 4401-03-02-0-05 |
| Max. flow | 60 l/min |
| Product family | (Z)3DRE(E)(A) |
| Type of connection | Sandwich plate |
| Conformity | UKCA |
| Supply voltage | 24 VDC |
| Connectivity | Analog, command value 0...10 V |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | P2 to P1 |
| Operating pressure, max. | 350 bar |
| Size | 6 |
| Seals | FKM |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Type of actuation | Electrical with on-board electronics |
| Weight | 3.5 kg |
Applications
The version is used in fixtures holding delicate parts that tolerate only a few dozen bar of clamping pressure. Pressure can be reset remotely during the cycle instead of being trimmed on a screw. UKCA conformity for electromagnetic compatibility is on file.
Manufacturer
Bosch Rexroth, material number R901551850. Characteristic curves, hysteresis and dimensions appear in the Bosch Rexroth documentation for the (Z)3DRE(E)(A) series.
| Hersteller-Nr | R901551850 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 3.500000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
