Proportional Directional Valve 4WRDE16V1-220L-6X/MPY/24F1 - Bosch Rexroth R901546609

Name: Proportional Directional Valve 4WRDE16V1-220L-6X/MPY/24F1 - Bosch Rexroth R901546609
Brand: Bosch Rexroth
SKU: BRR-R901546609
Price: 7090.52 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Current command with internal pilot supply: the 4WRDE16V1-220L-6X/MPY/24F1 follows a 4 ... 20 mA signal, saves the X line and drains pilot oil externally. 220 l/min nominal flow at 350 bar, valve mass 10.5 kg.

Net

€7,090.52

excl. VAT

Item BRR-R901546609

Manufacturer no. R901546609

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A current signal reveals a broken wire, and internal pilot supply saves a line. The 4WRDE16V1-220L-6X/MPY/24F1 combines both while controlling 220 l/min nominal flow at 350 bar operating pressure.

Benefits

4 ... 20 mA command, where any reading below 4 mA immediately shows an interrupted cable.
Internal pilot oil supply from the pressure port, external return through the Y line.
220 l/min nominal flow, up to 460 l/min maximum flow at 350 bar.
Spool symbol V1, linear characteristic, 3 switching positions on 4 ports.
10.5 kg valve mass on mounting pattern ISO 4401-07-07-0-05, 24 VDC supply.

Applications

A match for machines whose controller only offers current outputs, or whose signal paths suffer heavy interference from drives. Internal pilot supply keeps piping effort low. Where port P pressure collapses during the cycle, the external pilot supply version is the safe choice.

Manufacturer

Bosch Rexroth, material number R901546609, product family 4WRDE. NBR seals, HL hydraulic fluid.

Technical data

Connection diagram	ISO 4401-07-07-0-05
Max. flow	460 l/min
Product family	4WRDE
Type of connection	Subplate mounting
Nominal flow	220 l/min
Supply voltage	24 VDC
Connectivity	Analog, command value 4...20 mA
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector, 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol V1
Operating pressure, max.	350 bar
Size	16
Seals	NBR
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	10.5 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901546609
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
