Pressure Relief Valve DBW10B2-5X/240S6EG24N9K4R12E - Bosch Rexroth R901540282

Every hydraulic circuit needs a limit above which oil is released to tank. This pilot-operated pressure relief valve in size 10 takes on that job for flows up to 200 l/min and can be set in the range from 4 to 240 bar. The maximum operating pressure of the valve is 350 bar.

Benefits

• Setting range 4 to 240 bar for protecting the working circuit
• 200 l/min rated flow at 350 bar maximum operating pressure
• Pilot-operated poppet design for tight closing
• Internal hexagon with protective cap prevents unintended adjustment
• Subplate mounting to ISO 6264-06-09, weight 5.2 kg
• Solenoid unloading with 24 V DC, CE conform

Technical data

Applications

The valve sits in the pressure line of hydraulic power units and protects pump, piping and actuators against excess pressure. The mounted solenoid also allows the circuit to be unloaded electrically, for example during start-up or idle periods. The cap over the internal hexagon keeps the chosen setting in place.

Manufacturer

The manufacturer is Bosch Rexroth and the material number is R901540282. Full characteristic curves are given in data sheet RE 25802 and RE 25802-B.
