Instead of an analogue line one M12 cable is enough here: the valve is addressed over IO-Link and returns diagnostic data. Nominal flow is 60 l/min, operating pressure reaches 350 bar, spool symbol W8, weight 9.08 kg.
Proportional Directional Valve 4WRLE10W8-60LJ-4X/MPY/24L1 - Bosch Rexroth R901538060
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,825.08
Item
BRR-R901538060
Manufacturer no.
R901538060
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901538060
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901538060
Frequently Bought Together
-
This Item:
€4,825.08
-
Directional Spool Valve 5-4WE10H5X/EG205N9K4/V - Bosch Rexroth R901352976
€431.86
-
Directional Spool Valve 4WEH32J6X/6EG24N9ETK4/B10 - Bosch Rexroth R900932052
€4,158.16
Total price
Analogue command lines need shielding, calibration and a card of their own. This 4WRLE10W8-60LJ-4X is addressed over IO-Link instead, a 5-pole M12 x 1 connector with coding A carries signal and supply, at 60 l/min nominal flow.
Benefits
- IO-Link control removes the analogue card and the calibration of the command range.
- Connection through a 5-pole M12 x 1 connector, coding A, instead of a shielded analogue line.
- Spool symbol W8 with a widened fine range around the centre position.
- 60 l/min nominal flow, operating pressure to 350 bar, range maximum flow 300 l/min.
- Internal pilot oil take-off with external return, weight 9.08 kg, NBR seals.
Technical data
| Connection diagram | ISO 4401-05-05-0-05 |
| Max. flow | 300 l/min |
| Product family | 4WRLE |
| Type of connection | Subplate mounting |
| Nominal flow | 60 l/min |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Connectivity | IO-Link |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector, 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | Symbol W8 |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 5-pole, M12 x 1, coding A |
| Type of actuation | Electrical with on-board electronics |
| Weight | 9.08 kg |
Applications
The valve fits machines whose field level is already wired with IO-Link, for instance in packaging and assembly equipment. Parameters and status data travel on the same line as the command. Mounting pattern and subplate mounting follow ISO 4401-05-05-0-05 in size 10.
Manufacturer
Bosch Rexroth, material number R901538060. The type code 4WRLE10W8-60LJ-4X/MPY/24L1 states size 10, spool symbol W8, 60 l/min nominal flow and component series 4X.
