This version needs neither an external control oil line nor an analogue signal core: piloting is fully internal and control runs over IO-Link. It meters 100 l/min nominal flow at up to 350 bar and weighs 9.08 kg.
Proportional Directional Valve 4WRLE10V100L-4X/MPT/24L1 - Bosch Rexroth R901528052
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,521.59
Item
BRR-R901528052
Manufacturer no.
R901528052
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901528052
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901528052
Frequently Bought Together
-
This Item:
€4,521.59
-
Proportional Directional Valve 4WRLE25X370M-4X/MXY/24A1-811 - Bosch Rexroth R901474033
€6,176.18
-
Proportional Directional Valve 4WRLD16V1-250L-4X/MPT/24ED6T - Bosch Rexroth R901497635
€6,873.08
Total price
The shortest installation appears when oil and signal each need only one path. The 4WRLE10V100L-4X/MPT/24L1 feeds and drains pilot oil internally and communicates over IO-Link, at 100 l/min nominal flow and 350 bar.
Benefits
- Internal piloting in supply and return - connection through the four main bores only.
- IO-Link instead of an analogue signal, one M12 cable carries power and communication.
- 100 l/min nominal flow, 300 l/min maximum throughput, 350 bar operating pressure.
- Internal spool position feedback with linear characteristic, spool symbol V.
- Mass 9.08 kg, NBR seals, ISO 4401-05-05-0-05 interface.
Technical data
| Connection diagram | ISO 4401-05-05-0-05 |
| Max. flow | 300 l/min |
| Product family | 4WRLE |
| Type of connection | Subplate mounting |
| Nominal flow | 100 l/min |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Connectivity | IO-Link |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection | Connector, 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | Symbol V |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 5-pole, M12 x 1, coding A |
| Type of actuation | Electrical with on-board electronics |
| Weight | 9.08 kg |
Applications
Intended for series machines built to tight assembly times on a digital field layer. It assumes a system pressure that holds the minimum pilot pressure throughout the cycle, otherwise an externally supplied version is the better choice.
Manufacturer
Bosch Rexroth lists this valve under material number R901528052, type code 4WRLE10V100L-4X/MPT/24L1. Please quote that material number for queries about characteristic curves or installation dimensions.
| Hersteller-Nr | R901528052 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 9.080000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
