Proportional Directional Valve 4WRPEH10CB100L-3X/M/24A1 - Bosch Rexroth R901526078

Name: Proportional Directional Valve 4WRPEH10CB100L-3X/M/24A1 - Bosch Rexroth R901526078
Brand: Bosch Rexroth
SKU: BRR-R901526078
Price: 3302.89 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Spool symbol C and a rated flow of 100 l/min make the 4WRPEH10CB100L-3X/M/24A1 a valve for the standard case with a high oil demand. Its command value is a voltage of plus and minus 10 V. Operating pressure reaches 350 bar.

Net

€3,302.89

excl. VAT

Item BRR-R901526078

Manufacturer no. R901526078

Question about this item

Datasheet (PDF) User manual 12 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For many axes the standard port assignment is enough, as long as the flow is right. The 4WRPEH10CB100L-3X/M/24A1 combines spool symbol C with 100 l/min of rated flow and a command value of plus and minus 10 V.

Benefits

Rated flow of 100 l/min in size 10 at operating pressures up to 350 bar.
Command value of plus and minus 10 V at the on-board electronics, 24 V DC supply.
Internal piston position feedback keeps the spool at the commanded position.
Spool symbol C with four switching positions across four ports.
6.6 kg, NBR seals, connection diagram ISO 4401-05-04-0-05.

Applications

The valve feeds lifting cylinders, feeds and swivel drives that should travel briskly. At 6.6 kg it can be handled by one person during a change. The interface follows ISO 4401-05-04-0-05.

Manufacturer

The valve comes from Bosch Rexroth and carries material number R901526078 in product family 4WRPEH10.

Technical data

Connection diagram	ISO 4401-05-04-0-05
Product family	4WRPEH10
Type of connection	Subplate mounting
Nominal flow	100 l/min
Conformity	CE
Supply voltage	24 VDC
Connectivity	Command value input ±10 V
Number of switching positions	4
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol C
Operating pressure, max.	350 bar
Size	10
Seals	NBR
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	6.6 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901526078
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
