Proportional Directional Valve 4WRDE16W8-150L-6X/MPY/24A5 - Bosch Rexroth R901515167

Name: Proportional Directional Valve 4WRDE16W8-150L-6X/MPY/24A5 - Bosch Rexroth R901515167
Brand: Bosch Rexroth
SKU: BRR-R901515167
Price: 6994.72 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Take pilot oil internally but return it pressure free through its own tank port: the 4WRDE16W8-150L-6X/MPY/24A5 is built that way, works at 150 l/min nominal flow, up to 460 l/min flow and 350 bar. Weight 10.12 kg.

Net

€6,994.72

excl. VAT

Item BRR-R901515167

Manufacturer no. R901515167

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A high back pressure in the return line disturbs the piloting. The 4WRDE16W8-150L-6X/MPY/24A5 avoids that by taking pilot oil internally and returning it through an external port, at 150 l/min nominal flow and spool symbol W8.

Benefits

Internal pilot oil supply, so no additional pressure line is required
External pilot oil return, so back pressure in the main return does not affect the piloting
150 l/min nominal flow, 460 l/min maximum flow
Analogue command value ±10 V at the on-board electronics, 24 VDC supply
Spool symbol W8, three switching positions, 350 bar operating pressure, 10.12 kg

Application

A sensible choice in circuits with a filter or cooler in the return where noticeable back pressure builds up. Typical applications are presses, injection moulding machines and test axes in size 16. Subplate mounting follows ISO 4401-07-07-0-05.

Manufacturer

Bosch Rexroth, material number R901515167, product family 4WRDE, NBR seals for hydraulic fluid HL.

Technical data

Connection diagram	ISO 4401-07-07-0-05
Max. flow	460 l/min
Product family	4WRDE
Type of connection	Subplate mounting
Nominal flow	150 l/min
Supply voltage	24 VDC
Connectivity	Analog, command value ±10 V
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector, 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol W8
Operating pressure, max.	350 bar
Size	16
Seals	NBR
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	10.12 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901515167
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany

Downloads

Datasheet

Datasheet (PDF) PDF
Directional control valve, pilot-operated (RE 29097) PDF, 1.4 MB, 28 p. EN
Directional spool valves, direct operated (RE 23178) PDF, 1.2 MB, 28 p. EN
Directional spool valves, pilot-operated (RE 24751) PDF, 1.3 MB, 40 p. EN
Proportional directional valve, pilot-operated (RE 29115) PDF, 1.5 MB, 28 p. EN
Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) PDF, 1.5 MB, 28 p. DE
Regel-Wegeventile, vorgesteuert, mit elektrischer Wegrückführung und integrierter Elektronik (OBE) (RD 29097) PDF, 1.4 MB, 28 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung PDF, 1.2 MB, 28 p. DE
Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) PDF, 1.6 MB, 40 p. DE

User Manual

Hydraulic valves and hydroelectric pressure switches (RE 07600-B) PDF, 0.6 MB, 52 p. EN
