Proportional Directional Valve 4WRKE16E220L-3X/6EG24EK31/F1D3M - Bosch Rexroth R901496596

Name: Proportional Directional Valve 4WRKE16E220L-3X/6EG24EK31/F1D3M - Bosch Rexroth R901496596
Brand: Bosch Rexroth
SKU: BRR-R901496596
Price: 4294.91 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

On a paper machine axes run continuously and quietly at a steady command value. The 4WRKE16E220L takes its command value as 4...20 mA and meters 220 l/min nominal flow at 350 bar. Pilot oil arrives internally, the drain is routed outside.

Net

€4,294.91

excl. VAT

Item BRR-R901496596

Manufacturer no. R901496596

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Continuous duty calls for control that holds the same working point for hours. The 4WRKE16E220L-3X/6EG24EK31/F1D3M receives its command value as a 4...20 mA current, passes 220 l/min nominal flow and holds up to 350 bar operating pressure.

Benefits

4...20 mA current command value, low drift in continuous duty and over long cables
220 l/min nominal flow with spool symbol E in size 16
Internal pilot supply, external pilot drain, decoupled from the tank line
350 bar operating pressure, maximum flow 460 l/min
10.98 kg, NBR seals, 24 VDC, ISO 4401-07-07-0-05 connection diagram

Applications

The valve suits plants in continuous operation such as paper and film machines, belt drives and winding axes. On-board electronics process the command value at the valve, so no amplifier slot is occupied in the cabinet. The NBR seals match HL hydraulic fluid.

Manufacturer

Bosch Rexroth, material number R901496596, type code 4WRKE16E220L-3X/6EG24EK31/F1D3M. The suffix F1D3M identifies the current interface, EK31 the internal pilot supply with external drain.

Technical data

Connection diagram	ISO 4401-07-07-0-05
Max. flow	460 l/min
Product family	4WRKE
Type of connection	Subplate mounting
Nominal flow	220 l/min
Supply voltage	24 VDC
Connectivity	Analog, command value 4...20 mA
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol E
Operating pressure, max.	350 bar
Size	16
Seals	NBR
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	10.98 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901496596
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
