3/2 directional spool valve 3WE6B9-6X/EG110N9DL1/R12 size 6, 110 V DC - Bosch Rexroth R901490845
The 3/2 directional spool valve 3WE6B9-6X/EG110N9DL1/R12 switches oil flow at a maximum of 350 bar to control cylinders and hydraulic motors. Size 6 with connection diagram ISO 4401-03-02-0-05, solenoid actuation at 110 V DC.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
350 bar operating pressure and size 6: the 3WE6B9-6X/EG110N9DL1/R12 is a solenoid-operated 3/2 directional spool valve from Bosch Rexroth, material number R901490845.
Benefits
- Operating pressure up to 350 bar on the 3WE6B9-6X/EG110N9DL1/R12
- NBR seals for the hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HFC
- Conformity UKCA, CE (UKCA - Low-Voltage Directive SI2016/1101, CE - Low-Voltage Directive 2014/35/EU)
- Standardised connection diagram ISO 4401-03-02-0-05 for subplate mounting
- Solenoid actuation at 110 V DC, cable gland, terminal area 6 to 12 mm, with LED
Applications
The 3WE6B9-6X/EG110N9DL1/R12 valve is used in hydraulic power units, machine tools and machine-building systems, wherever a PLC sets the direction of motion of an actuator with a 110 V DC signal.
Check spool symbol B9 and size 6 against the hydraulic circuit diagram before ordering.
Technical data
| Type | 3WE6B9-6X/EG110N9DL1/R12 |
|---|---|
| Design | Directional spool valve with solenoid actuation |
| Size | 6 |
| Operating pressure, max. | 350 bar |
| Number of ports | 3 |
| Number of switching positions | 2 |
| Spool symbol | B9 |
| Connection diagram | ISO 4401-03-02-0-05 |
| Type of connection | Subplate mounting |
| Supply voltage | 110 V DC |
| Electrical connection | Cable gland, terminal area 6 to 12 mm, with LED |
| Seals | NBR |
| Hydraulic fluid | HL, HLP, HLPD, HVLP, HVLPD, HFC |
| Conformity | UKCA, CE |
| Conformity description | UKCA - Low-Voltage Directive SI2016/1101, CE - Low-Voltage Directive 2014/35/EU |
| Weight | 1.52 kg |
| Material number | R901490845 |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R901490845 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Seal material | NBR |
| Function | 3/2 |
| Actuation type | Electrical |
| Norm | ISO 4401 |
| Operating voltage | 110 V DC |
| Betriebsdruck max [bar] | 350 |
Downloads
Datasheet
- Datasheet (PDF)
- Directional spool valves, direct operated (RE 23178) EN
- Directional spool valves, pilot-operated (RE 24751) EN
- Proportional directional valve, pilot-operated (RE 29115) EN
- Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) DE
- Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung DE
- Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) DE
