Proportional Directional Valve 4WRPEH6C3B24L-3X/V/24C6 - Bosch Rexroth R901490377

The fourth switching position of the 4WRPEH6C3B24L-3X/V/24C6 is the fail-safe position of the safety shut-down. In operation the valve regulates 24 l/min nominal flow through symbol C3 at up to 350 bar operating pressure.

Benefits

• 24 l/min nominal flow in size 6, throughput up to 50 l/min.
• Spool symbol C3, four switching positions across four ports.
• Command value ±10 ma at the on-board electronics, 24 VDC supply.
• 350 bar maximum operating pressure on connection diagram ISO 4401-03-02-0-05.
• Safety shut-down with an additional fail-safe position for a defined rest position of the axis.
• 2.92 kg, FKM seals, 7-pole connector (6 + PE), direct actuated.

Technical data

Applications

The valve is fitted on small positioning and clamping axes, in machine tools, test rigs and handling equipment. 24 l/min nominal flow is enough for small cylinders that travel continuously. Subplate mounting to ISO 4401-03-02-0-05 is the usual interface in size 6.

Manufacturer

Bosch Rexroth, material number R901490377, product family 4WRPEH6. Hydraulic fluid HL, FKM seals, 24 VDC supply voltage, 7-pole connector (6 + PE).
