Spool symbol C1 defines how the ports are joined in the intermediate positions. The 4WRPEH6C1B40P-3X/V/24F1 meters 40 l/min nominal flow accordingly, runs on 4...20 mA and moves into a fail-safe position when required.
Proportional Directional Valve 4WRPEH6C1B40P-3X/V/24F1 - Bosch Rexroth R901477187
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,953.72
Item
BRR-R901477187
Manufacturer no.
R901477187
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901477187
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901477187
Frequently Bought Together
-
This Item:
€2,953.72
-
Directional Spool Valve 4WE 6 JA1X/HG24N9K4 - Bosch Rexroth R988129094
€142.54
-
Proportional Directional Valve 4WRLE25V400L-4X/MXT/24F1-834 - Bosch Rexroth R901439816
€6,910.67
Total price
Which ports are joined in the intermediate positions is set by the spool symbol. The 4WRPEH6C1B40P-3X/V/24F1 works to symbol C1, meters 40 l/min nominal flow and carries a safety shut-down with an additional fail-safe position.
Benefits
- Spool symbol C1 with 4 switching positions and 4 ports.
- Safety shut-down with an additional fail-safe position.
- 40 l/min nominal flow at a maximum of 50 l/min in size 6.
- Command value 4...20 mA into the on-board electronics, resistant to interference over longer cables.
- Operating pressure up to 350 bar at a mass of 3.12 kg.
- FKM seals for HL hydraulic fluid, supply 24 VDC.
Technical data
| Connection diagram | ISO 4401-03-02-0-05 |
| Product family | 4WRPEH6 |
| Type of connection | Subplate mounting |
| Nominal flow | 40 l/min |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Number of switching positions | 4 |
| Hydraulic fluid | HL |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Operating pressure, max. | 350 bar |
| Size | 6 |
| Seals | FKM |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Type of actuation | Electrical with on-board electronics |
| Max. flow | 50 l/min |
| Connectivity | Analog, command value 4...20 mA |
| Number of ports | 4 |
| Spool symbol | Symbol C1 |
| Weight | 3.12 kg |
Applications
The valve controls axes in forming and test equipment whose behaviour in intermediate and shut-down positions is written into the safety concept. The 4...20 mA current command stays stable over longer cable runs and shows a broken wire through the missing live zero. FKM seals are fitted for mineral oil of class HL.
Manufacturer
Bosch Rexroth, material number R901477187. The type code 4WRPEH6C1B40P-3X/V/24F1 states the 4WRPEH6 range in size 6 and component series 3X.
| Hersteller-Nr | R901477187 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 3.120000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
