Directional Spool Valve 5-4WE10D5X/OFEG110N9K4/A06M - Bosch Rexroth R901465864

Name: Directional Spool Valve 5-4WE10D5X/OFEG110N9K4/A06M - Bosch Rexroth R901465864
Brand: Bosch Rexroth
SKU: BRR-R901465864
Price: 452.56 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

For a directly operated valve, 150 l/min is the upper edge of size 10. The 5-4WE10D5X/OFEG110N9K4/A06M makes use of it, holds 350 bar operating pressure, weighs 5.41 kg and runs on a solenoid coil for 110 VDC.

Net

€452.56

excl. VAT

Item BRR-R901465864

Manufacturer no. R901465864

Question about this item

Datasheet (PDF) User manual 11 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Directly operated and still 150 l/min: in size 10 that is the upper end of the usable range. The 5-4WE10D5X/OFEG110N9K4/A06M switches that volume with spool symbol D in 2 positions at 350 bar.

Benefits

150 l/min flow at 350 bar across 4 ports in size 10.
Spool symbol D, 2 switching positions, ISO 4401-05-04-0-05 pattern.
110 VDC supply voltage, 3-pole (2 + PE) plug to EN 175301-803.
NBR seals for HL hydraulic fluid, 5.41 kg.
UKCA conformity under Low-Voltage Directive SI2016/1091.

Applications

The valve sits on axes that need a lot of oil in a short time, such as rapid traverse cylinders and lifting devices. Without a pilot stage there are no pilot lines and no minimum pilot pressure to observe. For a replacement, check coil voltage of 110 VDC alongside spool symbol and size.

Manufacturer

Bosch Rexroth lists this item under material number R901465864, product family 5-.WE10../E.

Technical data

Conformity description	UKCA - Low-Voltage Directive SI2016/1091
Connection diagram	ISO 4401-05-04-0-05
Max. flow	150 l/min
Product family	5-.WE10../E
Type of connection	Subplate mounting
Conformity	UKCA
Supply voltage	110 VDC
Number of switching positions	2
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Spool symbol	Symbol D
Operating pressure, max.	350 bar
Size	10
Seals	NBR
Electrical connector	Connector, 3-pole (2 + PE)
Type of actuation	with solenoid actuation
Weight	5.41 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901465864
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
