An axis with safety shut-down has to block reliably when it matters. The 4WRPE10E1-80S carries an additional ISA adapter for that and meters 80 l/min nominal flow at up to 350 bar in normal control duty. It is direct operated and weighs 7.77 kg.
Proportional Directional Valve 4WRPE10E1-80S-3X/V/24A1-A17 - Bosch Rexroth R901445335
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,297.75
Item
BRR-R901445335
Manufacturer no.
R901445335
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901445335
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901445335
Frequently Bought Together
-
This Item:
€4,297.75
-
Directional Spool Valve 4WE6GA6X/EG24N9DK24L - Bosch Rexroth R900924932
€298.74
-
Directional Spool Valve 4WE6JB6X/EG24NK4 - Bosch Rexroth R900924393
€170.38
Total price
An axis with safety shut-down has to block dependably on demand without spoiling normal control duty. The direct operated 4WRPE10E1-80S-3X/V/24A1-A17 combines an additional ISA adapter for shut-down with 80 l/min nominal flow in normal operation.
Benefits
- Additional ISA adapter for the safety shut-down of the axis
- 80 l/min nominal flow in size 10 at 350 bar operating pressure
- Direct operated with internal position feedback, no pilot circuit needed
- ±10 V command value input, supplied with 24 VDC through a 7-pole (6 + PE) plug
- Spool symbol E1, FKM seals, 7.77 kg, ISO 4401-05-04-0-94 connection diagram
Technical data
| Connection diagram | ISO 4401-05-04-0-94 |
| Product family | 4WRPE10 |
| Type of connection | Subplate mounting |
| Nominal flow | 80 l/min |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Connectivity | Command value input ±10 V |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | Symbol E1 |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | FKM |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Type of actuation | Electrical with on-board electronics |
| Weight | 7.77 kg |
Applications
The valve serves axes whose stopping is part of the machine safety concept, for example presses and test rigs with access during operation. The ISA adapter supplements the control function without affecting it in normal duty. Check the ISO 4401-05-04-0-94 pattern carefully when ordering a replacement.
Manufacturer
Bosch Rexroth, material number R901445335, type code 4WRPE10E1-80S-3X/V/24A1-A17. The suffix A17 marks the special version with ISA adapter, and special type 797 is recorded in the type code.
| Hersteller-Nr | R901445335 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 7.767000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
