Directional Spool Valve 5-4WE10D5X/EG125N9K4/M - Bosch Rexroth R901444076

Name: Directional Spool Valve 5-4WE10D5X/EG125N9K4/M - Bosch Rexroth R901444076
Brand: Bosch Rexroth
SKU: BRR-R901444076
Price: 304.43 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

On-board supplies of 125 V DC are common in power stations and rail technology. The 5-4WE10D5X/EG125N9K4/M fits them without a converter and switches 150 l/min at up to 350 bar.

Net

€304.43

excl. VAT

Item BRR-R901444076

Manufacturer no. R901444076

Question about this item

Datasheet (PDF) User manual 11 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Size 10 directional spool valve with spool symbol D for control systems on 125 V DC, rated for a flow of up to 150 l/min.

Key benefits

Solenoid rated 125 V DC, usable without an intermediate converter
Flow rate of 150 l/min at a maximum working pressure of 350 bar
2 switching positions to spool symbol D, 4 ports to ISO 4401-05-04-0-05
Weight of 4.1 kg on a size 10 subplate interface
NBR seals for HL hydraulic fluid, UKCA marking under SI2016/1091

Applications

The valve is intended for hydraulic power units in energy plants, rail vehicles and stationary emergency systems. Connection is made through a 3-pole connector (2 + PE) to EN 175301-803. It belongs to product family 5-.WE10../E.

Manufacturer

Bosch Rexroth lists this valve under material number R901444076. We supply original manufacturer parts.

Technical data

Conformity description	UKCA - Low-Voltage Directive SI2016/1091
Connection diagram	ISO 4401-05-04-0-05
Max. flow	150 l/min
Product family	5-.WE10../E
Type of connection	Subplate mounting
Conformity	UKCA
Supply voltage	125 VDC
Number of switching positions	2
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Spool symbol	Symbol D
Operating pressure, max.	350 bar
Size	10
Seals	NBR
Electrical connector	Connector, 3-pole (2 + PE)
Type of actuation	with solenoid actuation
Weight	4.1 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901444076
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany

Downloads

Datasheet

Datasheet (PDF) PDF
Directional spool valves, direct operated (RE 23178) PDF, 1.2 MB, 28 p. EN
Directional spool valves, direct operated (RE 23352) PDF, 0.9 MB, 24 p. EN
Directional spool valves, pilot-operated (RE 24751) PDF, 1.3 MB, 40 p. EN
Proportional directional valve, pilot-operated (RE 29115) PDF, 1.5 MB, 28 p. EN
Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) PDF, 1.5 MB, 28 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung PDF, 1.2 MB, 28 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung (RD 23352) PDF, 0.8 MB, 24 p. DE
Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) PDF, 1.6 MB, 40 p. DE
Distributeurs à tiroir, à commande directe, avec actionnement par électroaimant (RF 23352) PDF, 0.9 MB, 24 p. FR

User Manual

Hydraulic valves and hydroelectric pressure switches (RE 07600-B) PDF, 0.6 MB, 52 p. EN
