A fixed displacement unit keeps delivering while the machine waits, and that costs drive power. The PV7-1X/100-150RE07MD0-08-A184 adjusts its displacement of 150 cm³ on its own and supplies up to 218 l/min at a maximum of 80 bar.
Vane Pump PV7-1X/100-150RE07MD0-08-A184 - Bosch Rexroth R901439483
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,068.01
Item
BRR-R901439483
Manufacturer no.
R901439483
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901439483
Country of originGermany
Customs tariff number84136061
ConditionNew
Artikel
BRR-R901439483
Frequently Bought Together
-
This Item:
€6,068.01
-
Motorpumpengruppe ABAPG-AZPF-11-016LCB20M/ 1,1SJ4531/SESIE - Bosch Rexroth R920087658
€2,563.55
-
Vane Pump PVQ5-1X/193RJ15UVC - Bosch Rexroth R901095503
€3,570.49
Total price
During holding phases a machine needs no oil, and a fixed delivery is then lost as heat. The vane unit PV7-1X/100-150RE07MD0-08-A184 matches its displacement of 150 cm³ to demand and supplies up to 218 l/min.
Benefits
- Variable displacement of 150 cm³, delivery follows demand
- Up to 218 l/min at a maximum operating pressure of 80 bar
- Pressure controller with hydraulic remote adjustment of the setting
- With through-drive, further stages can be attached
- Shaft end cylindrical Ø 40 mm with fitting key to ISO 3019-2
- 4-hole mounting flange 160B4HW to ISO 3019-2, clockwise rotation, 57.8 kg
Technical data
| Direction of rotation | clockwise rotation |
| Displacement type | variable |
| Max. flow | 218 l/min |
| Product family | PV7...C/D/N/W |
| Through-drive | with |
| Hydraulic fluid | HLP |
| Shaft end | Cylindrical Ø 40 mm with fitting key, ISO 3019-2 |
| Operating pressure, max. | 80 bar |
| Size | 150 cm³ |
| Seals | NBR |
| Mounting flange | 4-hole mounting flange 160B4HW according to ISO 3019-2 |
| Weight | 57.8 kg |
Application
The unit feeds machine tools and production lines where working and holding phases alternate. Because the controller cuts delivery back as soon as the set pressure is reached, the oil stays cooler. The through-drive allows a second stage for a further circuit to be added.
Manufacturer
Bosch Rexroth, material number R901439483. The type designation PV7-1X/100-150RE07MD0-08-A184 names frame size, control and mounting.
| Hersteller-Nr | R901439483 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 57.800000 |
| Zolltarifnummer | 84136061 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
