A feed axis with medium demand should start smoothly and manage without an amplifier card. The 4WRPEH6C1B12L-3X/M/24F1 controls 12 l/min nominal flow from a 4...20 mA current command and passes 22 l/min at the limit.
Proportional Directional Valve 4WRPEH6C1B12L-3X/M/24F1 - Bosch Rexroth R901436252
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,232.79
Item
BRR-R901436252
Manufacturer no.
R901436252
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901436252
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901436252
Frequently Bought Together
-
This Item:
€2,232.79
-
Proportional Directional Valve 4WRTE16W9-220P-4X/6EG24K31/A5M - Bosch Rexroth R901388745
€5,854.43
-
Proportional Directional Valve 4WREE6E08-3X/V/24A1-655 - Bosch Rexroth R901496428
€4,428.73
Total price
Twelve litres per minute are enough for a brisk feed axis in size 6. The 4WRPEH6C1B12L-3X/M/24F1 sets that flow from an analogue 4...20 mA current command, with spool symbol C1 and a 22 l/min limit.
Advantages
- 12 l/min nominal flow, 22 l/min limit, reserve for short rapid phases of the axis.
- Spool symbol C1 with a 4...20 mA current command, the feedback loop sits inside the body.
- Maximum operating pressure 350 bar on the ISO 4401-03-02-0-05 pattern in size 6.
- 24 VDC supply voltage, electrical link Connector 3-pole (2 + PE) according to EN 175301-803.
- NBR seals for HL grade fluid, 2.98 kg mass.
Technical data
| Connection diagram | ISO 4401-03-02-0-05 |
| Product family | 4WRPEH6 |
| Type of connection | Subplate mounting |
| Nominal flow | 12 l/min |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Number of switching positions | 4 |
| Hydraulic fluid | HL |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Operating pressure, max. | 350 bar |
| Size | 6 |
| Seals | NBR |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Type of actuation | Electrical with on-board electronics |
| Max. flow | 22 l/min |
| Connectivity | Analog, command value 4...20 mA |
| Number of ports | 4 |
| Spool symbol | Symbol C1 |
| Weight | 2.98 kg |
Applications
The unit is used on feed and positioning axes in machine tools, presses and special machinery. A current command stays stable over long cable runs. The fourth switching position takes the axis into a defined state on signal loss.
Manufacturer
Bosch Rexroth, material number R901436252.
| Hersteller-Nr | R901436252 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 2.980000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
