Directional Spool Valve 4WE10Y11-5X/DEG26N5K4K/M - Bosch Rexroth R901433796

Not every axis needs a centre position. The directional spool valve 4WE10Y11-5X/DEG26N5K4K/M works with two switching positions in size 10 and is rated for a maximum operating pressure of 350 bar.

Benefits

• Two switching positions, four ports, spool symbol Y11.
• 350 bar maximum operating pressure in size 10.
• Supply voltage 26 VDC, direct solenoid actuation without a pilot stage.
• Connection diagram ISO 4401-05-04-0-05, subplate mounting, product family WE10../E.
• Connector 3-pole (2 + PE) according to EN 175301-803, NBR seals for HL fluid.
• 4.78 kg weight.

Technical data

Application

Clamping and gripping fixtures usually alternate between two states only, where a centre position would serve no purpose. This valve covers that case in size 10 up to 350 bar. The 26 V coil suits controls whose DC bus runs above the nominal 24 V. The ISO 4401-05-04-0-05 hole pattern is standard on size 10 control blocks.

Manufacturer

Bosch Rexroth, material number R901433796, product family WE10../E. Characteristic curves, switching times and performance limits are given in the data sheet Directional spool valves, direct operated (RE 23340), the range overview in RE 07600-B.
