Directional Spool Valve 4WEH16J7X/6EG24EK4/B10 - Bosch Rexroth R901424684

An oil flow of 300 l/min can only be switched by a pilot-operated stage, which is what the 4WEH16J7X/6EG24EK4/B10 is built for. The main spool in size 16 follows mounting pattern ISO 4401-07-07-0-05 at 280 bar maximum operating pressure. Spool symbol J splits the flow across four ports in three switching positions, the valve weighs 9.72 kg.

Benefits

• 300 l/min flow in size 16
• 280 bar maximum operating pressure
• Mounting pattern ISO 4401-07-07-0-05, subplate mounting with 4 ports
• Spool symbol J with 3 switching positions, pilot-operated main spool
• 24 VDC solenoid actuation, 3-pole connector (2 + PE) to EN 175301-803
• NBR seals, weight 9.72 kg

Technical data

Applications

The size is intended for large cylinders as well as press drives whose main circuit reaches 300 l/min. Pilot oil is supplied internally while the pilot oil return is external, so port Y has to run to tank without back pressure. Count the 9.72 kg of the valve into the fixing of the subplate.

Manufacturer

Bosch Rexroth lists the valve under material number R901424684 in product family H-4W.H.. Two manufacturer documents are on file, switching times as well as performance limit curves are given in the data sheet.
