Fixed displacement vane pump PVQ1-1X/027RJ15RMB, 27 cm³, 210 bar, 39 l/min, clockwise, NBR seals - Bosch Rexroth R901420518
The Bosch Rexroth PVQ1-1X/027RJ15RMB is an internally force compensated vane pump for 210 bar. Size 27 cm³, max. flow 39 l/min, NBR seals, clockwise.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Bosch Rexroth fixed displacement vane pump PVQ1-1X/027RJ15RMB works up to 210 bar and provides up to 39 l/min flow, clockwise.
Benefits
- Operating pressure up to 210 bar
- Flow up to 39 l/min at size 27 cm³
- 2-hole mounting flange 101-2 according to ISO 3019-1 for direct pump mounting
- NBR seals for HLP, HFC
- No hydraulic bearing load, which gives a long service life
- Good efficiency in mobile applications thanks to axial gap compensation
Applications
Mobile machinery and industrial power units are the field of use of the PVQ1-1X/027RJ15RMB. Without through-drive, the pump is driven on its own. Order reference is material number R901420518.
Technical data
| Type | PVQ1-1X/027RJ15RMB |
|---|---|
| Material number | R901420518 |
| Manufacturer | Bosch Rexroth |
| Product type | Vane pump, fixed displacement |
| Size | 27 cm³ |
| Operating pressure max. | 210 bar |
| Max. flow | 39 l/min |
| Direction of rotation | clockwise |
| Mounting flange | 2-hole mounting flange 101-2 according to ISO 3019-1 |
| Shaft end | Geared 22-4, 13T 16/32 DP, ISO 3019-1 |
| Through-drive | without |
| Seals | NBR |
| Hydraulic fluid | HLP, HFC |
| Weight | 12 kg |
| Hersteller-Nr | R901420518 |
| Zolltarifnummer | 84136061 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Seal material | NBR |
| Norm | ISO 3019-1 |
| Betriebsdruck max [bar] | 210 |
