A size 160 cartridge valve needs a control cover that defines its function. The LFA160D-2X/FV logic cover takes on that job for 2-way cartridge valves, is approved for up to 420 bar operating pressure and seals with FKM.
Logic Cover LFA160D-2X/FV - Bosch Rexroth R901404385
BOSCH REXROTH
Original product
Net price (excl. VAT)
€16,253.20
Item
BRR-R901404385
Manufacturer no.
R901404385
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901404385
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901404385
Frequently Bought Together
-
This Item:
€16,253.20
-
Logic Cover LFA125D-2X/FX60 - Bosch Rexroth R901527765
€8,575.06
-
Logic Cover LFA16GWA-7X/A10V - Bosch Rexroth R901488843
€563.60
Total price
The LFA160D-2X/FV logic cover closes off a size 160 2-way cartridge valve and determines its switching behaviour. Permissible operating pressure is 420 bar, the mounting cavity follows ISO 7368 and the version is sealed with FKM.
Benefits
- Operating pressure up to 420 bar, laid out for size 160 cartridge valves.
- Mounting cavity to ISO 7368, therefore matched to standardised valve blocks.
- FKM seals for fluids where NBR cannot be used.
- Subplate mounting, the cover is placed directly onto the cavity.
- Laid out for HL fluid, LFA product family from the preferred range.
Technical data
| Connection diagram | ISO 7368 |
| Product family | LFA |
| Type of connection | Subplate mounting |
| Hydraulic fluid | HL |
| Operating pressure, max. | 420 bar |
| Size | 160 |
| Seals | FKM |
| Weight | 225 kg |
Applications
The cover is used in large valve blocks of presses, injection moulding machines and metallurgical plants where 2-way cartridge valves switch the main flows. The cover defines how the cartridge valve is actuated and returned. The FKM version is chosen according to the medium carried in the circuit.
Manufacturer
The manufacturer is Bosch Rexroth, material number R901404385, product family LFA. Data sheet RE 21010 describes the 2-way cartridge valves and the matching covers, RE 07600-B places the series within the range.
| Hersteller-Nr | R901404385 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 225.000000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
