When a forming axis has to stand safely in mid position and then travel on at full flow: the 4WRPDH6C5B40L-2X/M/24VD6T links spool symbol C5 with 40 l/min nominal flow and 50 l/min maximum at 350 bar. Weight 3.56 kg.
Proportional Directional Valve 4WRPDH6C5B40L-2X/M/24VD6T - Bosch Rexroth R901378488
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,916.31
Item
BRR-R901378488
Manufacturer no.
R901378488
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901378488
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901378488
Frequently Bought Together
-
This Item:
€4,916.31
-
Directional Spool Valve Z4WEH22E63-5X/6EG24TK4QMABG24SO32 - Bosch Rexroth R901261819
€5,814.74
-
Directional Poppet Valve M-3SEW10C1X=420MG24N9K4SO894 - Bosch Rexroth R901322540
€854.20
Total price
Forming and testing axes often alternate between holding and fast travel. The 4WRPDH6C5B40L-2X/M/24VD6T carries spool symbol C5 with 40 l/min nominal flow for that purpose, releases up to 50 l/min and is driven through the on-board electronics of version 24VD6T.
Benefits
- Spool symbol C5 combined with 40 l/min nominal flow
- Maximum flow 50 l/min for fast travel phases
- Version 24VD6T, on-board electronics, 24 VDC supply
- Command value ±10 VDC or 4 ... 20 mA at the 12-pole connector (11 + PE)
- 350 bar operating pressure, 3.56 kg weight, connection diagram ISO 4401-03-02-0-05
Technical data
| Conformity description | UKCA - Electromagnetic compatibility (EMC) SI2016/1091 |
| Connection diagram | ISO 4401-03-02-0-05 |
| Max. flow | 50 l/min |
| Product family | 4WRPDH |
| Type of connection | Subplate mounting |
| Nominal flow | 40 l/min |
| Conformity | UKCA |
| Supply voltage | 24 VDC |
| Connectivity | ±10 VDC or 4 ... 20 mA |
| Number of switching positions | 4 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector, 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | Symbol C5 |
| Operating pressure, max. | 350 bar |
| Size | 6 |
| Seals | NBR |
| Electrical connector | Connector, 12-pole (11 + PE) |
| Type of actuation | Electrical with on-board electronics |
| Weight | 3.56 kg |
Application
The valve suits forming machines, test benches and lifting axes with frequent stops. The high nominal flow shortens travel times without calling for a second valve stage. Hydraulic fluid HL is intended and the seals are made of NBR.
Manufacturer
Bosch Rexroth, material number R901378488, product family 4WRPDH. Conformity UKCA, described as UKCA - electromagnetic compatibility (EMC) SI2016/1091.
| Hersteller-Nr | R901378488 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 3.560000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
