Directional Spool Valve 5-3WE10A5X/EG205N9K4/CM - Bosch Rexroth R901374358

Name: Directional Spool Valve 5-3WE10A5X/EG205N9K4/CM - Bosch Rexroth R901374358
Brand: Bosch Rexroth
SKU: BRR-R901374358
Price: 313.28 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

This size 10 directional spool valve uses three ports and switches to spool symbol A. Flow reaches 65 l/min at 350 bar operating pressure and the solenoid is wound for 205 VDC. With NBR seals and 4.2 kg it belongs in auxiliary circuits.

Net

€313.28

excl. VAT

Item BRR-R901374358

Manufacturer no. R901374358

Question about this item

Datasheet (PDF) User manual 11 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A shut-off or unloading circuit gets by with three ports. This directly actuated size 10 3/2 directional spool valve works to spool symbol A and carries up to 65 l/min at 350 bar.

Benefits

3 ports in 2 switching positions to spool symbol A
65 l/min maximum flow at 350 bar operating pressure
Solenoid actuation rated for 205 VDC
NBR seals for HL hydraulic fluid
Subplate mounting to ISO 4401-05-04-0-05
4.2 kg weight, UKCA conformity under Low-Voltage Directive SI2016/1091

Application

The article switches unloading, cooling and pre-load circuits in power units. It sits on the size 10 porting pattern even though only three ports are used. The supply comes from a 205 V rectifier circuit.

Manufacturer

Bosch Rexroth lists this article under material number R901374358.

Technical data

Conformity description	UKCA - Low-Voltage Directive SI2016/1091
Connection diagram	ISO 4401-05-04-0-05
Max. flow	65 l/min
Product family	5-.WE10../E
Type of connection	Subplate mounting
Conformity	UKCA
Supply voltage	205 VDC
Number of switching positions	2
Hydraulic fluid	HL
Number of ports	3
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Spool symbol	Symbol A
Operating pressure, max.	350 bar
Size	10
Seals	NBR
Electrical connector	Connector, 3-pole (2 + PE)
Type of actuation	with solenoid actuation
Weight	4.2 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901374358
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
