Where every kilogram on the manifold counts, weight and port count are worth a look. The 3WE10A5X/OFEG220K4/M weighs 4.27 kg, carries up to 120 l/min in size 10 and runs on 220 VDC. Spool symbol A, 2 switching positions, 350 bar.
Directional Spool Valve 3WE10A5X/OFEG220K4/M - Bosch Rexroth R901350294
BOSCH REXROTH
Original product
Net price (excl. VAT)
€402.24
Item
BRR-R901350294
Manufacturer no.
R901350294
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901350294
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R901350294
Frequently Bought Together
-
This Item:
€402.24
-
Directional Spool Valve 5-4WE10U32-5X/EG24N9K4/M - Bosch Rexroth R901336066
€502.84
-
Directional Spool Valve 4WE 6 J6X/EG24NDAL/62=CSA - Bosch Rexroth R978028627
€325.08
Total price
A valve with 3 ports and 4.27 kg puts little load on the manifold. The 3WE10A5X/OFEG220K4/M is built that way and carries up to 120 l/min in size 10.
Benefits
- 4.27 kg on subplate mounting to ISO 4401-05-04-0-05.
- 3 ports, 2 switching positions to spool symbol A.
- Up to 120 l/min at 350 bar operating pressure.
- 220 VDC supply voltage, 3-pole connector (2 + PE).
- NBR seals for HL hydraulic fluid, direct actuated.
Technical data
| Conformity description | UKCA - Low-Voltage Directive SI2016/1091 |
| Connection diagram | ISO 4401-05-04-0-05 |
| Max. flow | 120 l/min |
| Product family | WE10../E |
| Type of connection | Subplate mounting |
| Conformity | UKCA |
| Supply voltage | 220 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 3 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol A |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 4.27 kg |
Application
The valve is used for single-acting cylinders and cut-in functions in plants on 220 VDC. Three ports are enough when only one service port is switched. Mineral oil of class HL is intended for operation.
Manufacturer
Bosch Rexroth, material number R901350294. The item belongs to the WE10../E series and carries the UKCA marking under the Low Voltage Directive SI2016/1091.
