Pressure Relief Valve DBW30A2N5X/315-6EG24N9K4/12 - Bosch Rexroth R901185190

A separate pilot drain and symbol A often belong together inside a manifold. This size 32 version offers both and holds a value between 4 and 315 bar at a flow of up to 650 l/min.

Advantages

• Symbol A with a separately routed pilot drain
• Setting range 4 to 315 bar, maximum operating pressure 350 bar
• Flow up to 650 l/min, subplate mounting to ISO 6264-10-17
• Pilot-operated seat valve, 24 VDC coil, two switching positions
• Internal hexagon with protective cap, 6.49 kg, NBR seals for HL fluid

Technical data

Application

It is fitted into manifolds of power units whose return line runs through a cooler or a filter. Its own drain keeps the limit independent of the back pressure standing there. Once adjusted, the protective cap secures the result.

Manufacturer

Material number R901185190 at Bosch Rexroth, product family DB.10-30. Port allocation and curves are described in the data sheet.
