Proportional Directional Valve 4WRTE10E50L-4X/6EG24ETK31/A1V - Bosch Rexroth R901170280

Name: Proportional Directional Valve 4WRTE10E50L-4X/6EG24ETK31/A1V - Bosch Rexroth R901170280
Brand: Bosch Rexroth
SKU: BRR-R901170280
Price: 5442.63 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Between 25 and 100 l/min lies the grade that many medium axes need. The 4WRTE10E50L-4X/6EG24ETK31/A1V covers it with 50 l/min, works internally piloted and accepts ±10 V. Weight 9.44 kg, FKM seals.

Net

€5,442.63

excl. VAT

Item BRR-R901170280

Manufacturer no. R901170280

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The middle grade is the one most often installed in many plants. The 4WRTE10E50L-4X/6EG24ETK31/A1V delivers 50 l/min nominal flow, routes pilot oil internally and can be run with a ±10 V voltage command.

Benefits

50 l/min nominal flow as the middle grade in size 10.
Internal pilot oil supply and return, installation without X and Y lines.
Command value ±10 V through on-board electronics at 24 V DC.
Spool symbol E with a linear characteristic and internal spool position feedback.
9.44 kg weight at 350 bar maximum operating pressure, FKM seals.

Applications

The valve serves medium sized feed, lifting and slewing axes on machines running warm oil. Because the grade is common, spare part stocking can be built around it. Connection diagram ISO 4401-05-05-0-05, hydraulic fluid HL.

Manufacturer

Bosch Rexroth, material number R901170280, product family 4WRTE. The connector is 7-pole (6 + PE) according to EN 175201-804.

Technical data

Connection diagram	ISO 4401-05-05-0-05
Max. flow	170 l/min
Product family	4WRTE
Type of connection	Subplate mounting
Nominal flow	50 l/min
Supply voltage	24 VDC
Connectivity	Analog, command value ±10 V
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector, 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol E
Operating pressure, max.	350 bar
Size	10
Seals	FKM
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	9.44 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901170280
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany

Downloads

Datasheet

Datasheet (PDF) PDF
Directional control valves, pilot-operated, with electrical position feedback and integrated PDF, 1.3 MB, 32 p. EN
Directional spool valves, direct operated (RE 23178) PDF, 1.2 MB, 28 p. EN
Directional spool valves, pilot-operated (RE 24751) PDF, 1.3 MB, 40 p. EN
Proportional directional valve, pilot-operated (RE 29115) PDF, 1.5 MB, 28 p. EN
Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) PDF, 1.5 MB, 28 p. DE
Regel-Wegeventile, vorgesteuert, mit elektrischer Wegrückführung und integrierter Elektronik (OBE) PDF, 1.1 MB, 32 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung PDF, 1.2 MB, 28 p. DE
Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) PDF, 1.6 MB, 40 p. DE
