For machines working at around 170 bar the setting range from 4 to 170 bar is sufficient. The valve weighs 6.49 kg and is rated for 580 l/min. It sits on a subplate to ISO 6264-10-17 and is unloaded at 24 VDC.
Pressure Relief Valve DBW30B2N5X/170S6EG24N9K4R12E - Bosch Rexroth R901157645
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,194.91
Item
BRR-R901157645
Manufacturer no.
R901157645
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901157645
Country of originGermany
ConditionNew
Artikel
BRR-R901157645
Frequently Bought Together
-
This Item:
€2,194.91
-
Pressure Reducing Valve 3DR16P6-5X/200Y/00V - Bosch Rexroth R900917783
€2,497.16
-
HY-RückschlagventilS20P30-1X - Bosch Rexroth R900769828
€814.81
Total price
For machines working at around 170 bar the setting range from 4 to 170 bar is sufficient. The valve is rated for 580 l/min and sits on a subplate to ISO 6264-10-17. Unloading runs through a 24 VDC solenoid.
Benefits
- Setting range 4 to 170 bar for medium pressure circuits
- Flow up to 580 l/min in nominal size 32
- Pilot-operated seat valve with two switching positions
- Internal hexagon with protective cap secures the setting
- Solenoid unloading at 24 VDC, connector to EN 175301-803
- Weight 6.49 kg, CE compliant, NBR seals
Technical data
| Connection diagram | ISO 6264-10-17 |
| Max. flow | 580 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 350 bar |
| Size | 32 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 6.49 kg |
Application
Conveyors, lifting gear and clamping systems often work around 150 bar. A valve with a matching setting range can be trimmed more precisely there than one with a far higher upper limit. HL class hydraulic fluid is intended.
Manufacturer
Bosch Rexroth lists this item under material number R901157645. The datasheet holds the performance curves and the installation notes.
| Hersteller-Nr | R901157645 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 6.490000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
