Vane pump PVV1-1X/027RJ15DVB 27 cm³ 210 bar - Bosch Rexroth R901127013

Bosch Rexroth ✓ Original product Brand new Made in Germany

Fixed delivery of up to 39 l/min at 210 bar: the double-stroke vane pump PVV1-1X/027RJ15DVB with 27 cm³ runs without hydraulic bearing load. FKM seals, clockwise rotation, 2-hole mounting flange 101-2 to ISO 3019-1.

Net
€1,793.44
excl. VAT
Item BRR-R901127013
Manufacturer no. R901127013
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Bosch Rexroth PVV1-1X/027RJ15DVB is a vane pump of the PVV1 series with 27 cm³ displacement, rated for up to 210 bar.

Benefits

  • Double-stroke, internally force compensated: no hydraulic bearing load, which extends the service life of the PVV1-1X/027RJ15DVB.
  • 210 bar operating pressure at 39 l/min maximum flow and size 27 cm³.
  • Standard mounting: 2-hole mounting flange 101-2 to ISO 3019-1, shaft end geared 22-4, 13T 16/32 DP, ISO 3019-1.
  • FKM seals for hydraulic fluid HLP, HFD.

Applications

For hydraulic power units in industrial plants that need a constant delivery flow. Check the clockwise rotation and the flange before ordering, material number R901127013 defines the version.

Technical data

TypePVV1-1X/027RJ15DVB
Material numberR901127013
Size27 cm³
Displacement typefixed
Operating pressure max.210 bar
Max. flow39 l/min
Direction of rotationclockwise rotation
Mounting flange2-hole mounting flange 101-2 to ISO 3019-1
Shaft endGeared 22-4, 13T 16/32 DP, ISO 3019-1
Through-drivewithout
SealsFKM
Hydraulic fluidHLP, HFD
Weight12.36 kg
ManufacturerBosch Rexroth
Hersteller-NrR901127013
GPSR HerstellerdatenBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
Seal materialFKM
DichtungenFKM
NormISO 3019-1
Betriebsdruck max [bar]210
