A proportional valve sealed with NBR: 25 l/min nominal flow at spool symbol W6 in size 10. Flow reaches 170 l/min, operating pressure 315 bar, and weight comes to 8.16 kg, with control from external electronics on 24 V DC.
Proportional Directional Valve 4WRZ10W6-25-7X/6EG24N9K4/D3M - Bosch Rexroth R901120237
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,637.02
Item
BRR-R901120237
Manufacturer no.
R901120237
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901120237
Country of originGermany
ConditionNew
Artikel
BRR-R901120237
Frequently Bought Together
-
This Item:
€2,637.02
-
Directional Spool Valve 4WEH16E7X/6EG24ETK4QM0G24/B15 - Bosch Rexroth R900781115
€2,923.48
-
Directional Spool Valve 4WMM6G5X//V - Bosch Rexroth R900487265
€712.53
Total price
The 4WRZ10W6-25-7X/6EG24N9K4/D3M works with NBR seals at a nominal flow of 25 l/min. Spool symbol W6 sets the characteristic curve, flow reaches 170 l/min, operating pressure 315 bar, weight 8.16 kg.
Benefits
- NBR seals for HL hydraulic fluid
- 25 l/min nominal flow, flow up to 170 l/min
- Spool symbol W6, three switching positions, four ports
- Operating pressure up to 315 bar, 8.16 kg weight
- Electrical with external electronics, 24 VDC, connector 7-pole (6 + PE)
Technical data
| Connection diagram | ISO 4401-05-05-0-05 |
| Max. flow | 170 l/min |
| Product family | 4WRZ(E) |
| Type of connection | Subplate mounting |
| Nominal flow | 25 l/min |
| Supply voltage | 24 VDC |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector, 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | Symbol W6 |
| Operating pressure, max. | 315 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | Electrical with external electronics |
| Weight | 8.16 kg |
Applications
NBR suits HL mineral oil across the usual temperature range and is the common material in a standard circuit. A nominal flow of 25 l/min allows sensitive travel. Before swapping against an FKM version the oil compatibility has to be checked.
Manufacturer
The Bosch Rexroth material number is R901120237, the product family 4WRZ(E). Further data is given in datasheet RE 29115 and RE 07600-B.
| Hersteller-Nr | R901120237 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 8.160000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
