A size 63 two-way cartridge valve needs a control cover that fixes its opening travel and reports its position. The LFA63EHWMA2-7X/CA40DQ6G24P18 logic cover does both at operating pressure up to 420 bar in an ISO 7368 cavity.
Logic Cover LFA63EHWMA2-7X/CA40DQ6G24P18 - Bosch Rexroth R901086758
BOSCH REXROTH
Original product
Net price (excl. VAT)
€7,246.73
Item
BRR-R901086758
Manufacturer no.
R901086758
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901086758
Country of originGermany
ConditionNew
Artikel
BRR-R901086758
Frequently Bought Together
-
This Item:
€7,246.73
-
Logic Cover LFA40RF-7X/F15 - Bosch Rexroth R901006010
€1,179.48
-
Logic Cover LFA32KWB-7X - Bosch Rexroth R900912726
€699.15
Total price
Without a control cover a cartridge valve to ISO 7368 stays a dead part inside the manifold. This cover of the LFA ..E family controls a size 63 cartridge valve at up to 420 bar and limits the stroke by hand.
Benefits
- Operating pressure up to 420 bar in an ISO 7368 mounting cavity, size 63.
- Manual stroke limitation with hexagon and protective cap for the opening cross section that has been set.
- Spool position monitoring reports the state of the cartridge valve back to the controller.
- Subplate mounting on the cavity, HL hydraulic fluid, NBR seals.
- 63.6 kg weight in size 63.
Technical data
| Connection diagram | ISO 7368 |
| Product family | LFA ..E |
| Type of connection | Subplate mounting |
| Hydraulic fluid | HL |
| Operating pressure, max. | 420 bar |
| Size | 63 |
| Seals | NBR |
| Type of actuation | manual stroke limitation |
| Weight | 63.6 kg |
Application
The cover belongs on manifolds of large presses, rolling mills and injection moulding machines where two-way cartridge valves switch the main flow. Stroke limitation adapts the opening cross section to the machine. Position feedback allows interlocking inside the control sequence.
Manufacturer
Bosch Rexroth, material number R901086758, type designation LFA63EHWMA2-7X/CA40DQ6G24P18. Characteristic curves and installation dimensions are given in the Bosch Rexroth series documentation.
| Hersteller-Nr | R901086758 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 63.600000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
