Proportional Directional Valve 4WRKE32W6-600P-3X/6EG24EK31/F1D3V - Bosch Rexroth R901047149

Name: Proportional Directional Valve 4WRKE32W6-600P-3X/6EG24EK31/F1D3V - Bosch Rexroth R901047149
Brand: Bosch Rexroth
SKU: BRR-R901047149
Price: 8564.52 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Symbol W6 sets a different mid position behaviour than the E version, which matters on an emergency stop. The 4WRKE32W6-600P takes pilot oil internally, returns it externally, and meters 600 l/min of nominal flow up to 350 bar. Peak flow 1600 l/min.

Net

€8,564.52

excl. VAT

Item BRR-R901047149

Manufacturer no. R901047149

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The spool symbol decides what the cylinder does once the signal drops out. The 4WRKE32W6-600P-3X/6EG24EK31/F1D3V carries symbol W6, draws pilot oil internally from the pressure port and converts 600 l/min of nominal flow at up to 350 bar operating pressure.

Benefits

Symbol W6 with a defined mid position, matched to axes that have to hold load.
Internal pilot oil supply removes the external pilot circuit, only the return runs externally.
600 l/min nominal flow, peaking at 1600 l/min in size 32.
Command value 4 to 20 mA at the on-board electronics, powered from 24 V DC.
36.95 kg with FKM seals on connection diagram ISO 4401-10-09-0-05.

Applications

Intended for plants without a dedicated pilot pump, where system pressure serves as pilot oil. In presses or injection moulding machines symbol W6 keeps the axis settled in mid position. Three switching positions, four ports, subplate mounting to ISO.

Manufacturer

Bosch Rexroth, material number R901047149, product family 4WRKE. Pilot oil return runs externally, so line Y belongs in the layout.

Technical data

Connection diagram	ISO 4401-10-09-0-05
Max. flow	1600 l/min
Product family	4WRKE
Type of connection	Subplate mounting
Nominal flow	600 l/min
Supply voltage	24 V DC
Connectivity	Analog, command value 4 to 20 mA
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol W6
Operating pressure, max.	350 bar
Size	32
Seals	FKM
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	36.95 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901047149
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany

Downloads

Datasheet

Datasheet (PDF) PDF
Directional spool valves, direct operated (RE 23178) PDF, 1.2 MB, 28 p. EN
Directional spool valves, pilot-operated (RE 24751) PDF, 1.3 MB, 40 p. EN
Proportional directional valve, pilot-operated (RE 29115) PDF, 1.5 MB, 28 p. EN
Proportional directional valves, pilot-operated, with electrical position feedback and integrated PDF, 1.5 MB, 28 p. EN
Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) PDF, 1.5 MB, 28 p. DE
Proportional-Wegeventile, vorgesteuert, mit elektrischer Wegrückführung und integrierter Elektronik (RD 29075) PDF, 1.5 MB, 28 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung PDF, 1.2 MB, 28 p. DE
Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) PDF, 1.6 MB, 40 p. DE
