With spool symbol E51 this size 16 sandwich plate covers a different switching layout than the E63 version. It carries 300 l/min at 315 bar, is internally piloted and switched on 24 VDC. FKM seals and a weight of 15.3 kg complete the article.
Directional Spool Valve Z4WEH16E51-5X/6EG24N9ETK4/B10V - Bosch Rexroth R901046902
BOSCH REXROTH
Original product
Net price (excl. VAT)
€3,109.91
Item
BRR-R901046902
Manufacturer no.
R901046902
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901046902
Country of originGermany
ConditionNew
Artikel
BRR-R901046902
Frequently Bought Together
-
This Item:
€3,109.91
-
Proportional Directional Valve 4WRTE25W8-350L-4X/6EG24ETK31/F1M - Bosch Rexroth R901121430
€6,767.36
-
Directional Spool Valve H-4WMMH16E7X/6ET/B08D3 - Bosch Rexroth R901257705
€4,243.48
Total price
Within the Z4WEH16 series the spool symbol decides the switching function. This version with symbol E51 is built as a sandwich plate and carries up to 300 l/min at 315 bar operating pressure.
Benefits
- Spool symbol E51 with 2 switching positions across 4 ports
- Sandwich plate design for a size 16 valve stack
- 300 l/min maximum flow at 315 bar operating pressure
- Internal pilot oil supply and internal pilot oil return
- Concealed auxiliary actuation, solenoid actuation on 24 VDC
- FKM seals, connection diagram ISO 4401-07-07-0-05, 15.3 kg weight
Technical data
| Connection diagram | ISO 4401-07-07-0-05 |
| Max. flow | 300 l/min |
| Product family | Z.WEH16 |
| Type of connection | Sandwich plate |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol E51 |
| Operating pressure, max. | 315 bar |
| Size | 16 |
| Seals | FKM |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 15.3 kg |
Application
The article is fitted into stacked manifolds of presses, injection moulding machines and lifting gear. The concealed auxiliary actuation allows switching without control current. HL hydraulic fluid is covered by the FKM seals.
Manufacturer
Bosch Rexroth lists this article under material number R901046902. The Bosch Rexroth datasheets for this article are on file.
| Hersteller-Nr | R901046902 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 15.300000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
