Pressure Relief Valve DBW20B2-5X/140-6EG24N9K4E - Bosch Rexroth R901036511
Piping and fittings with a limited pressure rating often set 140 bar as the ceiling. This version covers 4 to 140 bar, discharges up to 400 l/min and weighs 5.36 kg. Adjustment is made on the internal hexagon under the protective cap.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The cylinder does not always dictate the pressure limit, often it is piping, hoses or fittings of an older design. A setting range of 4 to 140 bar keeps the circuit below such limits while the valve discharges the full 400 l/min. The subplate interface follows ISO 6264-08-13.
Benefits
- Setting range 4 to 140 bar, matched to limited line pressure ratings
- Flow up to 400 l/min in size 25
- Pilot-operated poppet valve with spool symbol B and two switching positions
- Internal hexagon with protective cap, subplate mounting to ISO 6264-08-13
- Solenoid actuation at 24 VDC, 3-pole connector (2 + PE) to EN 175301-803
- 5.36 kg mass, NBR seals for HL hydraulic fluid
Application
A typical case is a modernised existing machine whose piping was not replaced and whose pressure rating is therefore fixed. The limited setting range prevents the cut-off pressure from being turned beyond what the line is rated for. The solenoid switches the circuit without changing the stage.
Manufacturer
Bosch Rexroth lists this pressure relief valve DBW20B2-5X/140-6EG24N9K4E under material number R901036511. Data sheets RE 25802 and RE 25802-B carry the characteristic curves, the installation dimensions and the subplate data. Document the pressure rating of piping and fittings before setting the valve.
Technical data
| Connection diagram | ISO 6264-08-13 |
|---|---|
| Max. flow | 400 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 350 bar |
| Size | 25 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 5.36 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R901036511 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
