An axis without extra pilot oil lines to the plate needs a valve that routes pilot oil internally on its own. The 4WRTE25E350L-4X/6EG24ETK31/A1M supplies and returns pilot oil internally, at 350 l/min nominal flow, 350 bar operating pressure and 17.92 kg weight.
Proportional Directional Valve 4WRTE25E350L-4X/6EG24ETK31/A1M - Bosch Rexroth R900954282
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,510.01
Item
BRR-R900954282
Manufacturer no.
R900954282
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900954282
Country of originGermany
ConditionNew
Artikel
BRR-R900954282
Frequently Bought Together
-
This Item:
€6,510.01
-
Servo Directional Valve 4WSE2ED10-5X/20B9-315K31EV - Bosch Rexroth R901015625
€6,647.27
-
Directional Spool Valve 4WMM6J5X//B25 - Bosch Rexroth R900777170
€671.08
Total price
An axis without extra pilot oil lines to the plate needs a valve that routes pilot oil internally on its own. The 4WRTE25E350L-4X/6EG24ETK31/A1M supplies and returns pilot oil internally, at 350 l/min nominal flow, 350 bar operating pressure and 17.92 kg weight.
Advantages
- Internal pilot oil supply and internal return, no extra piping to the plate required.
- 350 l/min nominal flow at 350 bar operating pressure, maximum flow 870 l/min.
- Analog command value ±10 V with on-board electronics, 24 VDC supply.
- Spool symbol E with 3 switching positions across 4 ports.
- 17.92 kg weight on connection diagram ISO 4401-08-08-0-05, NBR seals for hydraulic fluid HL.
Technical data
| Connection diagram | ISO 4401-08-08-0-05 |
| Max. flow | 870 l/min |
| Product family | 4WRTE |
| Type of connection | Subplate mounting |
| Nominal flow | 350 l/min |
| Supply voltage | 24 VDC |
| Connectivity | Analog, command value ±10 V |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 7-pole (6 + PE) according to EN 175201-804 |
| Spool symbol | Symbol E |
| Operating pressure, max. | 350 bar |
| Size | 25 |
| Seals | NBR |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Type of actuation | Electrical with on-board electronics |
| Weight | 17.92 kg |
Applications
The valve suits axes where no extra pilot oil piping to the plate is possible or wanted, since supply and return of the pilot oil run internally. The analog command value ±10 V matches common controller outputs on machine tools and presses. The NBR seals cover the standard range for hydraulic fluid HL.
Manufacturer
Bosch Rexroth, material number R900954282.
| Hersteller-Nr | R900954282 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 17.920000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
