Directional Spool Valve H-4WEH25E6X/6EG24N9TK4/B08 - Bosch Rexroth R900950246

Name: Directional Spool Valve H-4WEH25E6X/6EG24N9TK4/B08 - Bosch Rexroth R900950246
Brand: Bosch Rexroth
SKU: BRR-R900950246
Price: 2041.78 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

A solenoid running on 24 V DC switches an oil flow of up to 700 l/min here. The pilot-operated size 25 valve withstands 350 bar, follows spool symbol E and weighs 17.78 kg. Pilot oil return runs internally.

Net

€2,041.78

excl. VAT

Item BRR-R900950246

Manufacturer no. R900950246

Question about this item

Datasheet (PDF) User manual 8 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

This valve turns an electrical signal into the reversal of large oil flows. At 24 V DC the solenoids switch up to 700 l/min at a maximum of 350 bar. Pilot oil supply comes from outside while the return stays internal.

Benefits

Solenoid actuation at 24 V DC through a connector 3-pole (2 + PE) according to EN 175301-803
700 l/min flow at a maximum operating pressure of 350 bar
Three switching positions with spool symbol E, size 25
External pilot oil supply with internal return
17.78 kg weight, four ports to ISO 4401-08-08-0-05, NBR seals

Application

The valve is used where a 24 V DC control system serves large hydraulic circuits. The connector to EN 175301-803 is widespread in machine building and easy to replace. Internal pilot return assumes low tank pressure.

Manufacturer

The material number is R900950246. Bosch Rexroth states power consumption and switching times in the datasheet.

Technical data

Connection diagram	ISO 4401-08-08-0-05
Max. flow	700 l/min
Product family	H-4W.H..
Type of connection	Subplate mounting
Supply voltage	24 VDC
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Spool symbol	Symbol E
Operating pressure, max.	350 bar
Size	25
Seals	NBR
Electrical connector	Connector, 3-pole (2 + PE)
Type of actuation	with solenoid actuation
Weight	17.78 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R900950246
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany

Downloads

Datasheet

Datasheet (PDF) PDF
Directional spool valves, direct operated (RE 23178) PDF, 1.2 MB, 28 p. EN
Directional spool valves, pilot-operated (RE 24751) PDF, 1.3 MB, 40 p. EN
Proportional directional valve, pilot-operated (RE 29115) PDF, 1.5 MB, 28 p. EN
Proportional-Wegeventil, vorgesteuert, ohne elektrische Wegrückführung, mit oder ohne integrierter (RD 29115) PDF, 1.5 MB, 28 p. DE
Wege-Schieberventile, direktgesteuert, mit Magnetbetätigung PDF, 1.2 MB, 28 p. DE
Wege-Schieberventile, vorgesteuert, mit hydraulischer oder elektro-hydraulischer Betätigung (RD 24751) PDF, 1.6 MB, 40 p. DE

User Manual

Hydraulic valves and hydroelectric pressure switches (RE 07600-B) PDF, 0.6 MB, 52 p. EN
