When a manifold is rebuilt, the weight on the hoist often decides. This H-4WEH25C6X version weighs 18.4 kg, switches 700 l/min at 350 bar and works to spool symbol C with two switching positions.
Directional Spool Valve H-4WEH25C6X/6EG24N9S2K4 - Bosch Rexroth R900936303
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,123.44
Item
BRR-R900936303
Manufacturer no.
R900936303
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900936303
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900936303
Frequently Bought Together
-
This Item:
€2,123.44
-
Directional Spool Valve 4WE6J73-6X/EG24N9K72L/A12=AN - Bosch Rexroth R901235372
€306.10
-
Directional Spool Valve 4WE10GA5X/EG205N9K4/M - Bosch Rexroth R901350235
€290.93
Total price
During assembly onto the manifold the valve usually hangs on lifting gear or is set by two people. This version of the H-4WEH25C6X weighs 18.4 kg while switching 700 l/min.
Benefits
- 18.4 kg at 700 l/min of flow in size 25.
- Spool symbol C with two switching positions across four ports.
- Maximum operating pressure of 350 bar at the pilot-operated main stage.
- External pilot oil supply and external pilot oil return.
- Subplate mounting to ISO 4401-08-08-0-05, 24 V DC solenoid, NBR seals.
Technical data
| Connection diagram | ISO 4401-08-08-0-05 |
| Max. flow | 700 l/min |
| Product family | H-4W.H.. |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol C |
| Operating pressure, max. | 350 bar |
| Size | 25 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 18.4 kg |
Applications
In manifolds carrying several large valves every kilogram counts during removal and refitting. Spool symbol C defines how the ports are connected at rest. NBR seals are fitted for HL hydraulic fluid.
Manufacturer
Bosch Rexroth lists this version under R900936303, product family H-4W.H... Installation dimensions are given in data sheet Directional spool valves, pilot-operated (RE 24751) and Hydraulic valves and hydro- (RE 07600-B).
| Hersteller-Nr | R900936303 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 18.400000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
